cub cadet lawn tractors 1914
 | 1985 - 1986
Garden tractor | 1985 - 1986 | Garden tractor |
|---|---|---|---|
1985 - 1986 | |||
Garden tractor | |||
1985 - 1986 | |
|---|---|
Garden tractor |
Production | |
|---|---|
Manufacturer | Cub Cadet (a part of MTD) |
Garden tractor | |
Built in Brownsville, Tennessee, USA | |
Variants | |
|---|---|
1912 | standard |
1914 | front hydraulics |
Cub Cadet 1914 Engine | |
|---|---|
19.9HP Onan 781cc 2-cyl gasoline | |
Fuel tank | 4 gal
15.1 L |
Engine details ...  | |
Cub Cadet 1914 Transmission | |
|---|---|
hydrostatic | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Disc brakes | |
Open operator station. |
Tractor hitch | |
|---|---|
Rear Type | 0 |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 2000 |
Front PTO | independent |
Clutch | electric |
Dimensions & Tires | |
|---|---|
Wheelbase | 51.6 inches
131 cm |
Weight | 978 lbs
443 kg |
Front tire | 18x8.50-8 |
Rear tire | 26x12.00-12 |
Full dimensions and tires ...  | |
Cub Cadet 1914 attachments | |
|---|---|
44" mid-mount mower deck | |
50" mid-mount mower deck | |
60" mid-mount mower deck | |
snowblower | |
blade | |
Attachment details ...  |
1914 Serial Numbers | |
|---|---|
Location: | Serial number decal on the right side of the 1914 frame, above the foot rest. |
1985 | 737625 |
1986 | 747225 |
FAQ: How to read a serial number table. | |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Charging amps | 20 |
Battery volts | 12 |
References | |
|---|---|
 | |
Home Tractors published in 1985, by Cub Cadet |
