yard man lawn tractors 13517
 | 1985 - 1986
Riding lawn mower | 1985 - 1986 | Riding lawn mower |
|---|---|---|---|
1985 - 1986 | |||
Riding lawn mower | |||
1985 - 1986 | |
|---|---|
Riding lawn mower |
Production | |
|---|---|
Manufacturer | Yard-Man (a part of MTD) |
Riding lawn mower | |
Yard-Man 13517 Engine | |
|---|---|
10HP Briggs & Stratton 399cc 1-cyl gasoline | |
Fuel tank | 1.5 gal
5.7 L |
Engine details ...  | |
Yard-Man 13517 Transmission | |
|---|---|
6-speed gear | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Disc brakes | |
Open operator station. |
Dimensions & Tires | |
|---|---|
Weight | 375 lbs
170 kg |
Front tire | 11.00x4.00 |
Rear tire | 16.00x6.50 |
Full dimensions and tires ...  | |
Yard-Man 13517 attachments | |
|---|---|
36" mid-mount mower deck | |
Attachment details ...  |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
Yard-Man Lawn & Garden Equipment published in 1984 |
