allis chalmers u

1929 - 1952

Standard-tread tractor

Standard-tread tractor

NTTL 170: Contintental 3-speed 2WD

NTTL 237: Waukesha 300 3-speed 2WD steel wheels

NTTL 237: Waukesha 300 3-speed 2WD rubber wheels

Contintental 3-speed 2WD October 21 - November 7, 1929 Link: Nebraska Tractor Test 170 file

Belt power (max)

35.04 hp 26.1 kW

Belt fuel use (max)

4.2 gal/hour 15.9 l/hour

Drawbar performance

Max power

25.63 hp 19.1 kW

Gear 1 used for power test.

Max pull

3,679 lbs 1668 kg

Gear 1 used for pull test.

Waukesha 300 3-speed 2WD steel wheels July 15 - August 5, 1935 Link: Nebraska Tractor Test 237 file

Belt power (max)

34.12 hp 25.4 kW

Belt fuel use (max)

4.1 gal/hour 15.5 l/hour

Drawbar performance

Max power

23.83 hp 17.8 kW

Gear 2 used for power test.

Max pull

3,428 lbs 1554 kg

Gear 1 used for pull test.

Waukesha 300 3-speed 2WD rubber wheels July 15 - August 5, 1935 Link: Nebraska Tractor Test 237 file

Belt power (max)

34.12 hp 25.4 kW

Belt fuel use (max)

4.1 gal/hour 15.5 l/hour

Drawbar performance

Max power

30.37 hp 22.6 kW

Gear 4 used for power test.

Max pull

2,452 lbs 1112 kg

Gear 2 used for pull test.
