Belarus MTZ-525

The Belarus MTZ-525 is a tractor produced by Belarus. It is equipped with a 289.8 ci 4.7 L engine. The rated power output is 67 hp 50.0 kW. Transmission: 9 forward and 2 reverse. Operating weight: 8,092 lbs 3670 kg.

Engine Power
67 hp 50.0 kW
Fuel & Capacities
29.1 gal 110.1 L
Transmission
9 forward and 2 reverse
Operating Weight
8,092 lbs 3670 kg

Belarus MTZ-525 Serial Number & Year Decoder

Find the exact manufacture year of your tractor by checking your chassis serial number below.

Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.

Overview

No photo available
1977 - 1983
1977 - 1983
Production
Manufacturer
Belarus
Variants
MTZ-505
2WD
Belarus MTZ-525 Engine
4.7L 4-cyl
Fuel tank
29.1 gal 110.1 L
Engine details ...
Belarus MTZ-525 Transmission
9-speed
Transmission details ...
Belarus MTZ-525 Power
Engine
67 hp 50.0 kW
Mechanical
Four-wheel drive
Steering
hydrostatic power
Disc brakes
standard
Hydraulics
Total flow
13.2 gpm 50.0 lpm
Tractor hitch
Rear lift
5,954 lbs 2700 kg
Power Take-off (PTO)
Rear PTO Type
540/ground
Dimensions & Tires
Wheelbase
96.5 inches 245 cm
Weight
8,092 lbs 3670 kg
Front tire
8.30-20
Rear tire
13.6-38
Full dimensions and tires ...
References
MTZ-525 references literature
Z200 Series published in 2019, by Kubota

Engine

Engine Detail — 289.8 ci / 4.7 L

Manufacturer
D60
Configuration
4-cylinder
Displacement
289.8 ci 4.7 L
Bore/Stroke
4.331x4.921 inches 110 x 125 mm
Power
67 hp 50.0 kW
Rated RPM
1800
Torque
193.3 lb-ft 262.1 Nm
Torque RPM
1100

Transmission

Transmission — 9 forward and 2 reverse

Gears
9 forward and 2 reverse

Dimensions

Belarus MTZ-525 Tires
Ag front
8.30-20
Ag rear
13.6-38
Dimensions
Wheelbase
96.5 inches 245 cm
Length
151.6 inches 385 cm
Height
109.8 inches 278 cm
Weight
8,092 lbs 3670 kg
