caseih 2130
 | 1988 - 1993
2100 SeriesOrchard/Vineyard tractorCarraro built | 1988 - 1993 | 2100 Series | Orchard/Vineyard tractor | Carraro built |
|---|---|---|---|---|---|
1988 - 1993 | |||||
2100 Series | |||||
Orchard/Vineyard tractor | |||||
Carraro built | |||||
1988 - 1993 | |
|---|---|
2100 Series | |
Orchard/Vineyard tractor | |
Carraro built |
Production | |
|---|---|
Distributor | CaseIH |
Manufacturer | Carraro |
Orchard/Vineyard tractor | |
Variants | |
|---|---|
2130V | vineyard |
2130E | narrow |
CaseIH 2130 Engine | |
|---|---|
SLH 3.0L 3-cyl diesel | |
Fuel tank | 15.85 gal
60.0 L |
Engine details ...  | |
CaseIH 2130 Transmissions | |
|---|---|
8-speed partially synchronized | |
12-speed partially synchronized | |
Transmission details ...  |
CaseIH 2130 Power | |
|---|---|
PTO (claimed) | 47 hp
35.0 kW |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Steering | hydrostatic power |
Wet disc brakes | |
Trailer brakes | hydraulic *Optional. |
Two-post forward-folding ROPS. Cab optional. | |
Hydraulics | |
|---|---|
Type | open center |
Valves | 1 or 2 |
Pump flow | 15.6 gpm
59.0 lpm |
Tractor hitch | |
|---|---|
Rear Type | I/II |
Control | position and draft control |
2130V Rear lift (at ends) | 5575 lbs
2528 kg |
2130E Rear lift (at ends) | 5463 lbs
2478 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540/750/1000 (1.375) |
Engine RPM | 540@2115 |
| 1000@2105 |
| 750@2015 |
Dimensions & Tires | |
|---|---|
2WD Wheelbase | 78 inches
198 cm |
4WD Wheelbase | 76.6 inches
194 cm |
Weight | 4101 to 4542 pounds |
Front tire | 5.50-16 |
2130V 2WD Rear tire | 13.6R28 |
Full dimensions and tires ...  | |
2130 Serial Numbers | |
|---|---|
Location: | Serial number plate on the right side of tractor's console. |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Charging amps | 55 |
Battery volts | 12 |
Battery AH | 100 |
References | |
|---|---|
 | |
Operators Manual 2120, 2130, 2140, 2150 V and E Tractors (9-13271) published in 1992 |
