CaseIH C50

The CaseIH C50 is a tractor produced by Caseih. It is equipped with a 165 ci 2.7 L engine. The listed engine power is Diesel (net): 48 hp / 35.8 kW; Diesel (gross): 53 hp / 39.5 kW. Transmission: 16 forward and 8 reverse. Operating weight: 5357 to 7595 pounds.

Overview

	1998 - 2002 CX Utility SeriesUtility tractor CX Utility Series Utility tractor

Production
Manufacturer	CaseIH
Utility tractor
Built in Doncaster, England
Original price was $19,700 in 1999

Variants
CX50	deluxe model
C50	basic model

CaseIH C50 Engine
Perkins 2.7L 3-cyl diesel
Engine details ...

CaseIH C50 Power
Engine (gross)	53 hp 39.5 kW
Engine (net)	48 hp 35.8 kW
PTO (claimed)	40 hp 29.8 kW
Drawbar (tested)	35.4 hp 26.4 kW
PTO (tested)	42.5 hp 31.7 kW
Performance test details ...

Mechanical
Two- or four-wheel drive
Differential lock	mechanical rear
Power steering
Differential hydraulic wet disc brakes
Two-post ROPS with straddle platform.

Capacity
Fuel	20 gal 75.7 L
2WD Hydraulic system	9 gal 34.1 L
4WD Hydraulic system	9.7 gal 36.7 L

Hydraulics
Type	open center
2WD Capacity	9 gal 34.1 L
4WD Capacity	9.7 gal 36.7 L
Pressure	2500 psi 172.4 bar
Valves	0 to 3
Pump flow	12.7 gpm 48.1 lpm
Total flow	15.7 gpm 59.4 lpm

Tractor hitch
Rear Type	II/I
Control	mechanical draft sensing
Rear lift	3665 lbs 1662 kg
	5097 lbsOptOptional 2311 kg

Power Take-off (PTO)
Rear PTO	independent
Clutch	hydraulic wet disc
Rear PTO Type	540
	540/1000 *Optional dual shaft

Dimensions & Tires
2WD Wheelbase	80.9 inches 205 cm
4WD Wheelbase	83.3 inches 211 cm
Weight	5357 to 7595 pounds
Front tire	7.50-16
Rear tire	14.9-28
Full dimensions and tires ...

Electrical
Ground	negative
Charging system	alternator
Charging amps	65
Battery CCA	650
	810 (optional)
Battery volts	12

References
CX Series Tractors published in 1997, by CaseIH

Engine

Engine Detail — 165 ci / 2.7 L Diesel

Manufacturer	Perkins 903.27
Fuel Type	Diesel
Configuration	3-cylinder, liquid-cooled
Displacement	165 ci 2.7 L
Bore/Stroke	3.74x5.00 inches 95 x 127 mm
Power (net)	48 hp 35.8 kW
Power (gross)	53 hp 39.5 kW
Fuel system	mechanical direct injection with 5-hole injectors
Air cleaner	dual paper elements
Compression	17.25:1
Rated RPM	2250
Torque	140 lb-ft 189.8 Nm
Torque RPM	1200
Starter volts	12
Oil capacity	8 qts 7.6 L
Oil change	250 h
Coolant capacity	12.57 qts 11.9 L

Transmission

Transmission options
8-speed
16-speed partial power shift
16-speed creeper

Transmission — 8 forward and 4 reverse

Gears	8 forward and 4 reverse
Clutch	12-inch dry disc
2WD Oil capacity	36 qts 34.1 L
4WD Oil capacity	38.6 qts 36.5 L

Transmission — 16 forward and 8 reverse partial power shift

Type	partial power shift
Gears	16 forward and 8 reverse
Clutch	12-inch dry disc
2WD Oil capacity	36 qts 34.1 L
4WD Oil capacity	38.6 qts 36.5 L

Transmission — 8 forward and reverse

Gears	8 forward and reverse
2WD Oil capacity	36 qts 34.1 L
4WD Oil capacity	38.6 qts 36.5 L
Transmission
Type	creeper
Gears	16 forward and 8 reverse

Dimensions

CaseIH C50 Tires
Ag front	7.50-16
Ag rear	14.9-28

Dimensions
2WD Wheelbase	80.9 inches 205 cm
4WD Wheelbase	83.3 inches 211 cm

CaseIH C50 Weight
2WD Shipping	5357 lbs 2429 kg
4WD Shipping	6096 lbs 2765 kg
Operating	7595 lbs 3445 kg
Max capacity	10,150 lbs 4604 kg

Tests

OCED Tractor Test 1893
Diesel 16-speed 4WD April 1999 - June 1999, Link: OCED Tractor Test 1893 file
PTO performance
Power at rated engine speed	42.5 hp 31.7 kW
Fuel use	2.8 gal/hour 10.6 l/hour
Power at rated PTO speed	40.9 hp 30.5 kW
Fuel use	2.6 gal/hour 9.8 l/hour
Drawbar performance
Max power	35.4 hp 26.4 kW
Fuel use	2.8 gal/hour 10.6 l/hour
Gear 1-High-TA used for power test.
Max pull	7990 lbs 3624 kg
Gear 1-Low-Direct used for pull test.

Attachments

Attachment overview
CaseIH 2200 loader
CaseIH 2250 loader
