CaseIH Steiger 555

The CaseIH Steiger 555 is a tractor produced by Caseih. It is equipped with a 787 ci 12.9 L engine. The rated power output is 547.4 hp 408.2 kW. Transmission: CVXDrive. Operating weight: 46340 lbs 21019 kg.

Overview

	2024 - Steiger 4WD SeriesFour-wheel Drive (4WD) tractor
2024 -
Steiger 4WD Series
Four-wheel Drive (4WD) tractor

2024 -
Steiger 4WD Series
Four-wheel Drive (4WD) tractor

Production
Manufacturer	CaseIH (a part of CNH)
Four-wheel Drive (4WD) tractor
Built in Fargo, North Dakota, USA

CaseIH Steiger 555 Engine
FPT 12.9L 6-cyl diesel
Fuel tank	455 gal 1722.2 L
Exhaust fluid (DEF)	66 gal 249.8 L
Engine details ...

CaseIH Steiger 555 Transmissions
17-speed full power shift
continuously-variable transmission
Transmission details ...

CaseIH Steiger 555 Power
Engine (gross)	547.4 hp 408.2 kW
Engine (max)	605.6 hp 451.6 kW
PTO (claimed)	529.6 hp 394.9 kW

Mechanical
Four-wheel drive
Final drives	planetary
Differential lock	automatic front and rear
Articulated power steering
Cab standard with air-conditioning.

Hydraulics
Type	closed center
Valves	4 to 8
Pump flow	42 gpm 159.0 lpm
	57 gpmOptOptional 215.7 lpm
	113 gpmOptOptional 427.7 lpm
SCV flow	35 gpm 132.5 lpm

Tractor hitch
Rear Type	IVN
Rear lift (at 24"/610mm)	22750 lbs 10319 kg
Drawbar	Cat 4
	Cat 5 OptOptional

Power Take-off (PTO)
Rear PTO	independent
Rear PTO Type	1000 (1.75)

Dimensions & Tires
Wheelbase	154 inches 391 cm
Weight	46340 lbs 21019 kg
Full dimensions and tires ...

Electrical
Ground	negative
Charging system	alternator
Charging amps	240
	330 OptOptional
Batteries	3
Battery CCA	950
Battery volts	12

References
TAFS Connect Steiger published in 2024, by New Holland

Engine

	2024 - Steiger 4WD SeriesFour-wheel Drive (4WD) tractor
2024 -
Steiger 4WD Series
Four-wheel Drive (4WD) tractor

2024 -
Steiger 4WD Series
Four-wheel Drive (4WD) tractor

Engine Detail
FPT Cursor 13
turbocharged diesel
6-cylinder 24-valve
liquid-cooled
Displacement	787 ci 12.9 L
Bore/Stroke	5.31x5.91 inches 135 x 150 mm
Emissions	Tier IV
Rated Power (gross)	547.4 hp 408.2 kW
Maximum Power (gross)	605.6 hp 451.6 kW
Rated RPM	2100
Starter	electric
Starter volts	12

CaseIH Steiger 555 Engine

Transmission

	2024 - Steiger 4WD SeriesFour-wheel Drive (4WD) tractor
2024 -
Steiger 4WD Series
Four-wheel Drive (4WD) tractor

2024 -
Steiger 4WD Series
Four-wheel Drive (4WD) tractor

Transmission options
17-speed full power shift
continuously-variable transmission

Transmission
Transmission	PowerDrive
Type	full power shift
Gears	17 forward and 2 reverse

Speeds

CaseIH Steiger 555 Transmission

Transmission
Transmission	CVXDrive
Type	continuously-variable transmission
Gears	infinite forward and reverse

CaseIH Steiger 555 Transmission

Dimensions

	2024 - Steiger 4WD SeriesFour-wheel Drive (4WD) tractor
2024 -
Steiger 4WD Series
Four-wheel Drive (4WD) tractor

2024 -
Steiger 4WD Series
Four-wheel Drive (4WD) tractor

CaseIH Steiger 555 Tires

Dimensions
Wheelbase	154 inches 391 cm
Front axle	Bar: 5 by 120 inches 127 by 3048 mm
Bar rear axle	5 by 120 inches 127 by 3048 mm

CaseIH Steiger 555 Weight
Shipping	46340 lbs 21019 kg
Max capacity	60000 lbs 27216 kg
Max Drawbar	6000 lbs (Cat 4) 2721 kg
	11000 lbs (Cat 4)OptOptional 4989 kg
	15000 lbs (Cat 5) 6804 kg
