challenger mt535b
 | 2004 - 2011
Model year 2004-20072007-2011
MT500B SeriesRow-Crop tractor | 2004 - 2011 | Model year 2004-20072007-2011 | MT500B Series | Row-Crop tractor |
|---|---|---|---|---|---|
2004 - 2011 | |||||
Model year 2004-20072007-2011 | |||||
MT500B Series | |||||
Row-Crop tractor | |||||
2004 - 2011 | |
|---|---|
Model year 2004-20072007-2011 | |
MT500B Series | |
Row-Crop tractor |
Tractor Tests | |
|---|---|
OECD 2213: diesel AutoPower IV 4WD | |
OECD 2194: diesel CVT 4WD |
OCED Tractor Test 2213 | ||
|---|---|---|
 | | |
| ||
|
|---|
OCED Tractor Test 2213 | |
|---|---|
Diesel AutoPower IV 4WD
May 2004 - June 2004,
Link: OCED Tractor Test 2213 file | |
PTO performance | |
Max power | 116.3 hp
86.7 kW |
Fuel use | 7.0 gal/hour
26.5 l/hour |
Power at rated engine speed | 105.9 hp
79.0 kW |
Fuel use | 7.3 gal/hour
27.6 l/hour |
Power at rated PTO speed | 112.9 hp
84.2 kW |
Fuel use | 7.2 gal/hour
27.3 l/hour |
Drawbar performance | |
Max power | 79.1 hp
59.0 kW |
Fuel use | 6.7 gal/hour
25.4 l/hour |
Gear 4TA used for power test. | |
Max pull | 12,345 lbs
5599 kg |
Gear 1TD used for pull test. | |
OCED Tractor Test 2194 | ||
|---|---|---|
 | | |
| ||
|
|---|
OCED Tractor Test 2194 | |
|---|---|
Diesel CVT 4WD
February 2004 - March 2004,
Link: OCED Tractor Test 2194 file | |
PTO performance | |
Max power | 118.1 hp
88.1 kW |
Fuel use | 7.2 gal/hour
27.3 l/hour |
Power at rated engine speed | 106.7 hp
79.6 kW |
Fuel use | 7.4 gal/hour
28.0 l/hour |
Power at rated PTO speed | 114.5 hp
85.4 kW |
Fuel use | 7.6 gal/hour
28.8 l/hour |
Drawbar performance | |
Max power | 103.8 hp
77.4 kW |
Fuel use | 8.8 gal/hour
33.3 l/hour |
Pull at 7.7 KPH | |
Max pull | 15,040 lbs
6822 kg |
Pull at 3.6 KPH | |
