claas 35
 | Agricultural Crawler tractor | Agricultural Crawler tractor |
|---|---|---|
Agricultural Crawler tractor | ||
Agricultural Crawler tractor |
|---|
Note: the Claas model Challenger 35 is the same as the Challenger 35. The following data is from the 35 listing. |
|---|
Production | |
|---|---|
Manufacturer | Claas |
Agricultural Crawler tractor | |
Original price was $118,875 in 1998 | |
Claas 35 Engine | |
|---|---|
Caterpillar 6.6L 6-cyl diesel | |
Fuel tank | 85 gal
321.7 L |
| 125 gal*Optional.
473.1 L |
Engine details ...  | |
Claas 35 Transmissions | |
|---|---|
16-speed full power shift | |
32-speed creeper | |
Transmission details ...  |
Claas 35 Power | |
|---|---|
Engine | 210 hp
156.6 kW |
Drawbar (claimed) | 150 hp
111.9 kW |
PTO (claimed) | 175 hp
130.5 kW |
Mechanical | |
|---|---|
Drive | crawler |
Steering | differential power |
Wet disc brakes | |
Cab standard with air-conditioning. | |
Photos | |
|---|---|
 | |
Claas 35 photos...  |
Hydraulics | |
|---|---|
Type | variable-displacement load-sensing pressure-compensated |
Pressure | 2750 psi
189.6 bar |
Valves | 3 or 4 |
Pump flow | 31.2 gpm
118.1 lpm |
Tractor hitch | |
|---|---|
Rear Type | III/II |
Control | draft control |
Rear lift | 12500 lbs
5670 kg |
| 15000 lbs*Optional.
6804 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Clutch | electro-hydraulic wet disc |
Rear PTO Type | 1000 (1.75) |
Engine RPM | 1000@1900 |
Dimensions & Tracks | |
|---|---|
Wheelbase | 86 inches
218 cm |
Weight | 22262 lbs
10098 kg |
16-inch tracks | |
Full dimensions and tracks ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Battery volts | 12 |
