Cockshutt 1450
The Cockshutt 1450 is a tractor produced by Cockshutt. It is equipped with a 268.3 ci 4.4 L engine. Transmission: Ampli-couple. Operating weight: 6000 lbs 2721 kg.
Fuel & Capacities
21 gal
79.5 L
Transmission
Ampli-couple
Operating Weight
6000 lbs
2721 kg
Cockshutt 1450 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1966 - 1969 | 1966 - 1969 |
|---|
Series map: 1350145048.9hp*61.1hp**Estimated engine power for comparison only.
Note: the Cockshutt model 1450 is the same as the Oliver 1450. The following data is from the 1450 listing. |
Production | |
|---|---|
Manufacturer | Cockshutt |
Built in Italy | |
Original price was $6,000 in 1969 | |
Cockshutt 1450 Engine | |
|---|---|
Fiat 4.4L 4-cyl diesel | |
Fuel tank | 21 gal
79.5 L |
Engine details ...  | |
Cockshutt 1450 Power | |
|---|---|
PTO (claimed) | 55 hp
41.0 kW |
Plows | 3 to 4 |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Steering | power optional |
Open operator station. | |
Hydraulics | |
|---|---|
Type | open center |
Pump flow | 7 gpm
26.5 lpm |
Tractor hitch | |
|---|---|
Rear Type | II |
Rear lift (at ends) | 4400 lbs
1995 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | live |
Rear PTO Type | 540 |
Dimensions & Tires | |
|---|---|
Weight | 6000 lbs
2721 kg |
Front tire | 6.50-18 |
Rear tire | 14.9-30 |
Full dimensions and tires ...  | |
Engine
Series map: 1350145048.9hp*61.1hp**Estimated engine power for comparison only.
Note: the Cockshutt model 1450 is the same as the Oliver 1450. The following data is from the 1450 listing. |
Engine Detail — 268.3 ci / 4.4 L Diesel
Manufacturer | Fiat |
Fuel Type | Diesel |
Configuration | 4-cylinder, liquid-cooled |
Displacement | 268.3 ci
4.4 L |
Bore/Stroke | 4.25x4.75 inches
108 x 121 mm |
Air cleaner | oil bath |
Compression | 15.5:1 |
Rated RPM | 1900 |
Starter volts | 12 |
Oil capacity | 9 qts
8.5 L |
Coolant capacity | 20 qts
18.9 L |
Transmission
Series map: 1350145048.9hp*61.1hp**Estimated engine power for comparison only.
Note: the Cockshutt model 1450 is the same as the Oliver 1450. The following data is from the 1450 listing. |
Transmission options | |
|---|---|
7-speed sliding gear | |
14-speed |
Transmission — 7 forward and 2 reverse sliding gear
Type | sliding gear |
Gears | 7 forward and 2 reverse |
Oil capacity | 23 qts
21.8 L |
With 16.9-30 rear tires. | |
 | |
Transmission — Ampli-couple
Transmission | Ampli-couple |
Gears | 14 forward and 4 reverse |
Oil capacity | 23 qts
21.8 L |
With 16.9-30 rear tires. | |
 | |
Dimensions
Series map: 1350145048.9hp*61.1hp**Estimated engine power for comparison only.
Note: the Cockshutt model 1450 is the same as the Oliver 1450. The following data is from the 1450 listing. |
Cockshutt 1450 Tires | |
|---|---|
Ag front | 6.50-18 |
8.3-24 | |
9.5-24 | |
Ag rear | 14.9-30 |
16.9-30 | |
18.4-26 | |
Dimensions | |
|---|---|
Length | 135.9 inches
345 cm |
Width | 58.25 inches*Minimum width.
147 cm |
Height (steering wheel) | 66.5 inches
168 cm |
Height (hood) | 58.1 inches
147 cm |
Shipping weight | 6000 lbs
2721 kg |
Ground clearance | 18.25 inches
46 cm |
Attachments
Series map: 1350145048.9hp*61.1hp**Estimated engine power for comparison only.
Note: the Cockshutt model 1450 is the same as the Oliver 1450. The following data is from the 1450 listing. |
