Cockshutt 1900

The Cockshutt 1900 is a tractor produced by Cockshutt. It is equipped with a 212 ci 3.5 L engine. The rated power output is 100.62 hp 75.0 kW. Transmission: Hydra-Power. Operating weight: 12000 lbs 5443 kg.

Overview

	1963 - 1964 Row-Crop tractor
1963 - 1964
Row-Crop tractor

Series map: 1800190085.6hp*99.3hp**Estimated engine power for comparison only.

Note: the Cockshutt model 1900 is the same as the Oliver 1900. The following data is from the 1900 listing.

Production
Manufacturer	Cockshutt
Row-Crop tractor
Built in Charles City, Iowa, USA
Original price was $9,000 in 1964

Cockshutt 1900 Engine
General Motors 3.5L 4-cyl diesel
Engine details ...

Cockshutt 1900 Power
Drawbar (tested)	88.27 hp 65.8 kW
PTO (tested)	100.62 hp 75.0 kW
Performance test details ...

Mechanical
Two- or four-wheel drive
Steering	manual
	power (late)
Differential dry disc brakes
Open operator station.

Capacity
Fuel	31.5 gal 119.2 L
Hydraulic system	5 gal 18.9 L

Hydraulics
Capacity	5 gal 18.9 L
Pump flow	13 gpm 49.2 lpm

Tractor hitch
Rear Type	II/I

Power Take-off (PTO)
Rear PTO	independent
Rear PTO Type	540
	1000
Engine RPM	1000@2000

Dimensions & Tires
Wheelbase	97.25 inches 247 cm
Weight	12000 lbs 5443 kg
Front tire	7.50-18
Rear tire	18-26
Full dimensions and tires ...

References
1600-1800-1900 Hydra-Power Drive published in 1964, by Cockshutt
New Cockshutt Row Crop and Wheatland Tractors published in 1962

Engine

Series map: 1800190085.6hp*99.3hp**Estimated engine power for comparison only.

Note: the Cockshutt model 1900 is the same as the Oliver 1900. The following data is from the 1900 listing.

Engine Detail — 212.4 ci / 3.5 L Diesel

Manufacturer	General Motors 4-53
Configuration	4-cylinder, liquid-cooled
blower diesel
Displacement	212.4 ci 3.5 L
Bore/Stroke	3.875x4.50 inches 98 x 114 mm
Air cleaner	oil bath
Compression	17:1
Rated RPM	2000
Starter volts	12
Oil capacity	14.5 qts 13.7 L
Coolant capacity	21 qts 19.9 L

Cockshutt 1900 Engine

Engine Detail — 212 ci / 3.5 L Diesel

Manufacturer	General Motors 4-53
Configuration	4-cylinder, liquid-cooled
blower diesel
Series B engine, used from 1962 to 1964.
Displacement	212 ci 3.5 L
Bore/Stroke	3.875x4.50 inches 98 x 114 mm
Air cleaner	oil bath
Compression	21:1
Rated RPM	2200
Starter volts	12

Transmission

Series map: 1800190085.6hp*99.3hp**Estimated engine power for comparison only.

Note: the Cockshutt model 1900 is the same as the Oliver 1900. The following data is from the 1900 listing.

Transmission options
6-speed unsynchronized gear
12-speed partial power shift

Transmission — 6 forward and 2 reverse unsynchronized gear

Type	unsynchronized gear
Gears	6 forward and 2 reverse
Clutch	dry disc

Transmission — Hydra-Power

Transmission	Hydra-Power
Type	partial power shift
Gears	12 forward and 4 reverse
Clutch	dry disc

Dimensions

Series map: 1800190085.6hp*99.3hp**Estimated engine power for comparison only.

Note: the Cockshutt model 1900 is the same as the Oliver 1900. The following data is from the 1900 listing.

Cockshutt 1900 Tires
Ag front	7.50-18
Ag rear	18-26
Ag rear	15-34

Dimensions
Wheelbase	97.25 inches 247 cm
Length	156.6 inches 397 cm
Width	97 inches*Minimum width. 246 cm
Height (steering wheel)	76 inches 193 cm
Operating weight	12000 lbs 5443 kg
Ballasted weight	18355 lbs 8325 kg
Ground clearance	23.875 inches 60 cm
Front tread	69.5 inches 176 cm
Rear tread	74/82 inches 187/208 cm

Tests

Series map: 1800190085.6hp*99.3hp**Estimated engine power for comparison only.

Note: the Cockshutt model 1900 is the same as the Oliver 1900. The following data is from the 1900 listing.

Tractor Tests
NTTL 768: diesel 6-speed 2WD
NTTL 824: Series B diesel 12-speed 2WD
NTTL 847: Series B diesel 12-speed 4WD

Nebraska Tractor Test 768
Diesel 6-speed 2WD October 3 - 8, 1960 Link: Nebraska Tractor Test 768 file
PTO performance
Max power	89.35 hp 66.6 kW
Fuel use	6.2 gal/hour 23.5 l/hour
Drawbar performance
Max power	82.85 hp 61.8 kW
Fuel use	6.4 gal/hour 24.2 l/hour
Gear 4 used for power test.
Max pull	12,475 lbs 5658 kg
Gear 1 used for pull test.

Nebraska Tractor Test 824
Series B diesel 12-speed 2WD September 17 - 23, 1962 Link: Nebraska Tractor Test 824 file
PTO performance
Power at rated engine speed	98.54 hp 73.5 kW
Fuel use	6.6 gal/hour 25.0 l/hour
Drawbar performance
Max power	84.44 hp 63.0 kW
Fuel use	6.5 gal/hour 24.6 l/hour
Gear 4-Direct used for power test.
Max pull	13,471 lbs 6110 kg
Gear 2-Hydra-Power used for pull test.

Nebraska Tractor Test 847
Series B diesel 12-speed 4WD September 13 - 20, 1963 Link: Nebraska Tractor Test 847 file
PTO performance
Power at rated engine speed	100.62 hp 75.0 kW
Fuel use	7.5 gal/hour 28.4 l/hour
Drawbar performance
Max power	88.27 hp 65.8 kW
Fuel use	7.2 gal/hour 27.3 l/hour
Gear 4-Direct used for power test.
Max pull	16,991 lbs 7707 kg
Gear 1-Direct used for pull test.

Photos

Cockshutt 1900
