Craftsman 502.27011
The Craftsman 502.27011 is a tractor produced by Craftsman Lawn Tractors. It is equipped with a 357 cc 21.82 ci engine. The rated power output is 10 hp 7.5 kW. Transmission: Dana 4450.
Engine Power
10 hp
7.5 kW
Fuel & Capacities
0.75 gal
2.8 L
Transmission
Dana 4450
Craftsman Lawn Tractors Craftsman 502.27011 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 2001
Riding lawn mowerMurray built |
|---|---|
2001 | |
Riding lawn mower | |
Murray built | |
2001 | |
|---|---|
Riding lawn mower | |
Murray built |
Production | |
|---|---|
Distributor | Craftsman (a part of Sears) |
Manufacturer | Murray |
Riding lawn mower | |
Craftsman 502.27011 Engine | |
|---|---|
10HP Tecumseh 357cc 1-cyl gasoline | |
Fuel tank | 0.75 gal
2.8 L |
Engine details ...  | |
Craftsman 502.27011 Transmission | |
|---|---|
5-speed gear | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Open operator station. |
Power Take-off (PTO) | |
|---|---|
Mid PTO | independent |
Clutch | manual |
Dimensions & Tires | |
|---|---|
Rear tire | 16x6.5 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging amps | 3 |
Battery volts | 12 |
References | |
|---|---|
 | |
A Complete Line of 2001 Riding Equipment and Attachments published by Sears |
Engine
| 2001
Riding lawn mowerMurray built |
|---|---|
2001 | |
Riding lawn mower | |
Murray built | |
2001 | |
|---|---|
Riding lawn mower | |
Murray built |
Engine Detail — 357 cc / 21.82 ci Gasoline
Manufacturer | Tecumseh TVM220 |
Fuel Type | Gasoline |
Configuration | 1-cylinder, air-cooled vertical-shaft |
Displacement | 357 cc
21.82 ci |
Bore/Stroke | 3.31x2.53 inches
84 x 64 mm |
Power | 10 hp
7.5 kW |
Starter | electric |
Starter volts | 12 |
Oil capacity | 1 qts
0.9 L |
Sparkplug | Champion RJ4C |
Sparkplug gap | 0.030 inches
0.762 mm |
Transmission
| 2001
Riding lawn mowerMurray built |
|---|---|
2001 | |
Riding lawn mower | |
Murray built | |
2001 | |
|---|---|
Riding lawn mower | |
Murray built |
Transmission — Dana 4450
Transmission | Dana 4450 |
Type | belt-driven gear |
Gears | 5 forward and 1 reverse |
 | |
Dimensions
| 2001
Riding lawn mowerMurray built |
|---|---|
2001 | |
Riding lawn mower | |
Murray built | |
2001 | |
|---|---|
Riding lawn mower | |
Murray built |
Craftsman 502.27011 Tires | |
|---|---|
Lawn/turf rear | 16x6.5 |
Dimensions |
|---|
Attachments
| 2001
Riding lawn mowerMurray built |
|---|---|
2001 | |
Riding lawn mower | |
Murray built | |
2001 | |
|---|---|
Riding lawn mower | |
Murray built |
30" Mower deck | |
|---|---|
Type | mid-mount Craftsman |
1-blade with manual lift | |
Cutting width | 30 inches
76 cm |
Cut height | 1.5 to 4 inch
3 to 10 cm |
Cut positions | 8 |
Photos
Craftsman 502.27011 tractor photo
Craftsman Lawn Tractors Craftsman 502.27011 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Craftsman Lawn Tractors Craftsman 502.27011.
Converted Equivalents:
Horsepower (HP)10 hp
Kilowatts (kW)7.5 kW
Metric Horsepower (PS / CV)10.1 PS
