Craftsman 917.25471 YT 14
The Craftsman 917.25471 YT 14 is a tractor produced by Craftsman Lawn Tractors. It is equipped with a 655 cc 40 ci engine. The rated power output is 14 hp 10.4 kW. Transmission: Foote 4150-61. Operating weight: 487 lbs 220 kg.
Engine Power
14 hp
10.4 kW
Fuel & Capacities
3.5 gal
13.2 L
Transmission
Foote 4150-61
Operating Weight
487 lbs
220 kg
Craftsman Lawn Tractors Craftsman 917.25471 YT 14 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1989
Lawn tractorRoper built |
|---|---|
1989 | |
Lawn tractor | |
Roper built | |
1989 | |
|---|---|
Lawn tractor | |
Roper built |
Production | |
|---|---|
Distributor | Craftsman (a part of Sears) |
Manufacturer | Roper |
Lawn tractor | |
Craftsman 917.25471 Engine | |
|---|---|
14HP Briggs & Stratton 655cc 2-cyl gasoline | |
Fuel tank | 3.5 gal
13.2 L |
Engine details ...  | |
Craftsman 917.25471 Transmission | |
|---|---|
5-speed gear | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Mechanical disc brakes | |
Open operator station. |
Power Take-off (PTO) | |
|---|---|
Mid PTO | independent |
Clutch | manual |
Mid PTO Type | pulley |
Dimensions & Tires | |
|---|---|
Weight | 487 lbs
220 kg |
Front tire | 15x6.00-6 |
Rear tire | 18x9.5-8 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
Craftsman Lawn and Garden Riding Equipment and Attachments published in 1989, by Sears |
Engine
| 1989
Lawn tractorRoper built |
|---|---|
1989 | |
Lawn tractor | |
Roper built | |
1989 | |
|---|---|
Lawn tractor | |
Roper built |
Engine Detail — 655 cc / 40 ci Gasoline
Manufacturer | Briggs & Stratton 400707 |
Fuel Type | Gasoline |
Configuration | 2-cylinder, air-cooled vertical-shaft opposed-twin |
Displacement | 655 cc
40 ci |
Bore/Stroke | 3.44x2.16 inches
87 x 55 mm |
Power (gross) | 14 hp
10.4 kW |
Starter | electric |
Starter volts | 12 |
Craftsman 917.25471 Engine | |
|---|---|
 |
Transmission
| 1989
Lawn tractorRoper built |
|---|---|
1989 | |
Lawn tractor | |
Roper built | |
1989 | |
|---|---|
Lawn tractor | |
Roper built |
Transmission — Foote 4150-61
Transmission | Foote 4150-61 |
Type | belt-driven gear |
Gears | 5 forward and 1 reverse |
Dimensions
| 1989
Lawn tractorRoper built |
|---|---|
1989 | |
Lawn tractor | |
Roper built | |
1989 | |
|---|---|
Lawn tractor | |
Roper built |
Craftsman 917.25471 Tires | |
|---|---|
Lawn/turf front | 15x6.00-6 |
Lawn/turf rear | 18x9.5-8 |
Dimensions | |
|---|---|
Length | 64 inches
162 cm |
Weight | 487 lbs
220 kg |
Attachments
| 1989
Lawn tractorRoper built |
|---|---|
1989 | |
Lawn tractor | |
Roper built | |
1989 | |
|---|---|
Lawn tractor | |
Roper built |
Attachment overview | |
|---|---|
38" mid-mount mower deck | |
Snowblower | |
Blade | |
The 25471 was compatible with the model 917.24246 21-inch belt-drive tiller. |
38" Mower deck | |
|---|---|
Type | mid-mount Craftsman |
manual lift | |
Cutting width | 38 inches
96 cm |
Overall width | 49 inches
124 cm |
Cut height | 1.5 to 4.0 inch
3 to 10 cm |
Photos
Craftsman 917.25471 YT 14 tractor photo
Craftsman Lawn Tractors Craftsman 917.25471 YT 14 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Craftsman Lawn Tractors Craftsman 917.25471 YT 14.
Converted Equivalents:
Horsepower (HP)14 hp
Kilowatts (kW)10.4 kW
Metric Horsepower (PS / CV)14.2 PS
