craftsman lawn tractors 917 27314
 | 2003
LT 2000 SeriesLawn tractorAYP built | 2003 | LT 2000 Series | Lawn tractor | AYP built |
|---|---|---|---|---|---|
2003 | |||||
LT 2000 Series | |||||
Lawn tractor | |||||
AYP built | |||||
2003 | |
|---|---|
LT 2000 Series | |
Lawn tractor | |
AYP built |
Production | |
|---|---|
Distributor | Craftsman (a part of Sears) |
Manufacturer | AYP |
Lawn tractor | |
Craftsman 917.27314 Engine | |
|---|---|
17HP Kohler 490cc 1-cyl gasoline | |
Fuel tank | 1.25 gal
4.7 L |
Engine details ...  | |
Craftsman 917.27314 Transmission | |
|---|---|
hydrostatic | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Open operator station. |
Power Take-off (PTO) | |
|---|---|
Mid PTO | independent |
Clutch | manual |
Dimensions & Tires | |
|---|---|
Front tire | 15x6.0-6 |
Rear tire | 20x10-8 |
Full dimensions and tires ...  | |
Craftsman 917.27314 attachments | |
|---|---|
42" mid-mount mower deck | |
Attachment details ...  |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
2003 Riding Equipment and Attachments published by Sears |
