Craftsman 944.60265

The Craftsman 944.60265 is a tractor produced by Craftsman Lawn Tractors. The listed engine power is Gasoline (gross): 22 hp / 16.4 kW. Transmission: Tuff Torq K46BT.

Engine Power

Gasoline (gross): 22 hp / 16.4 kW

Fuel & Capacities

Gasoline

Transmission

Tuff Torq K46BT

Overview

	2012 Lawn tractorAYP built Lawn tractor AYP built

Production
Distributor	Craftsman (a part of Sears)
Manufacturer	AYP
Lawn tractor
Original price was CAD$1,800 in 2012

Craftsman 944.60265 Engine
16.4KW Briggs & Stratton 2-cyl gasoline
Engine details ...

Craftsman 944.60265 Transmission
hydrostatic
Transmission details ...

Mechanical
Two-wheel drive
Manual steering
Open operator station.

Power Take-off (PTO)
Mid PTO	independent
Clutch	manual
Mid PTO Type	pulley

Dimensions & Tires
Front tire	15x6.00-6
Rear tire	20x8.00-8
Full dimensions and tires ...

Electrical
Ground	negative
Battery volts	12

References

Owner's Manual 944.602650 Lawn Tractor (448239) published in 2012

Engine

Engine Detail — Gasoline

Manufacturer	Briggs & Stratton 407777
Fuel Type	Gasoline
Configuration	2-cylinder, air-cooled vertical-shaft V-Twin
Power (gross)	22 hp 16.4 kW
Starter	electric
Starter volts	12

Transmission

Transmission — Tuff Torq K46BT

Transmission	Tuff Torq K46BT
Type	belt-driven hydrostatic
Gears	infinite forward and reverse

Dimensions

Craftsman 944.60265 Tires
Lawn/turf front	15x6.00-6
Lawn/turf rear	20x8.00-8

Dimensions

Attachments

42" Mower deck
Type	mid-mount Craftsman
	2-blade with manual lift
Cutting width	42 inches 106 cm

Recommended Implements & Sizing Guide

Engineering recommendations for Craftsman Lawn Tractors Craftsman 944.60265 based on its 22 HP power envelope and ASAE agricultural standards.

Implement & Operation	Recommended Size	Workload Rating	Engineering Notes
Moldboard PlowPrimary Tillage	1 to 2 Bottom (12")1 - 2 铧 (30 cm)	Light Duty	Ideal for garden plots and light sandy soil.
Rotary Cutter / MowerMowing & Clearing	4 ft (48 in)1.2 m	Light Duty	Pasture clipping and light brush under 1" diameter.
Rotary TillerSeedbed Prep	42 to 48 in105 - 120 cm	Light Duty	Covers compact tractor tire width.
Disc HarrowSecondary Tillage	5 to 6 ft (16-18" discs)1.5 - 1.8 m (40-45 cm 耙片)	Light Duty	Small acreage soil break-up and secondary aeration.

Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.

Fluids, Capacities & Working Autonomy

Standard fluid requirements, service intervals, and continuous runtime estimates for Craftsman Lawn Tractors Craftsman 944.60265.

Engine Crankcase Oil

SAE 15W-40 (Heavy Duty Diesel)

Standard Spec: API CK-4 / CJ-4 Heavy Duty

Service Interval: 150 – 250 Hours

Transmission & Hydraulic System

UTTO (Universal Tractor Transmission Oil)

Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)

Service Interval: 600 – 1000 Hours

Engine Cooling System

50/50 Ethylene Glycol Pre-mix

Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze

Service Interval: 2 Years / 1500 Hours

Craftsman Lawn Tractors Craftsman 944.60265 Specification Unit Converter

Convert power, fluid capacities, and operating weights between metric and imperial standards for Craftsman Lawn Tractors Craftsman 944.60265.

Enter value:

Unit:

Converted Equivalents:

Horsepower (HP)22 hp

Kilowatts (kW)16.4 kW

Metric Horsepower (PS / CV)22.3 PS

Direct Competitor Comparison

Compare Craftsman 944.60265 against same-era industry alternatives in the same horsepower class.

Current Model

Craftsman Lawn Tractors
