cub cadet 7194
 | 1996 - 1997
7000 SeriesCompact Utility tractorMitsubishi built | 1996 - 1997 | 7000 Series | Compact Utility tractor | Mitsubishi built |
|---|---|---|---|---|---|
1996 - 1997 | |||||
7000 Series | |||||
Compact Utility tractor | |||||
Mitsubishi built | |||||
1996 - 1997 | |
|---|---|
7000 Series | |
Compact Utility tractor | |
Mitsubishi built |
Production | |
|---|---|
Distributor | Cub Cadet |
Manufacturer | Mitsubishi |
Compact Utility tractor | |
Original price | $13,000 (1997) |
Variants | |
|---|---|
7192 | 2WD Gear |
7193 | 2WD Hydrostatic |
7194 | 4WD Gear |
7195 | 4WD Hydrostatic |
Cub Cadet 7194 Engine | |
|---|---|
Mitsubishi 1.1L 3-cyl diesel | |
Fuel tank | 5.3 gal
20.1 L |
Engine details ...  | |
Cub Cadet 7194 Transmission | |
|---|---|
6-speed partially synchronized gear | |
Transmission details ...  |
Cub Cadet 7194 Power | |
|---|---|
Engine | 19 hp
14.2 kW |
PTO (claimed) | 16.5 hp
12.3 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Differential lock | rear standard |
Steering | hydrostatic power |
Expanding dry shoe brakes | |
Two-post foldable ROPS. | |
Photos | |
|---|---|
 | |
Cub Cadet 7194 photos...  |
Hydraulics | |
|---|---|
Type | open center |
Pressure | 2133 psi
147.1 bar |
Pump flow | 5.4 gpm
20.4 lpm |
Steering flow | 3.2 gpm
12.1 lpm |
Tractor hitch | |
|---|---|
Rear Type | I |
Control | position control |
Rear lift (at ends) | 1400 lbs
635 kg |
Rear lift (at 24"/610mm) | 980 lbs
444 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | live independent |
Rear PTO Type | 540 (1.375) |
Mid PTO | live independent |
Mid PTO Type | 2000 |
Dimensions & Tires | |
|---|---|
Wheelbase | 57.9 inches
147 cm |
Weight | 1964 lbs
890 kg |
Front tire | 6.00-12 |
Rear tire | 9.50-16 |
Full dimensions and tires ...  | |
Cub Cadet 7194 attachments | |
|---|---|
60" mid-mount mower deck | |
front-end loader | |
Attachment details ...  |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
Full Line published in 1995, by Cub Cadet | |
Full Line published in 1996, by Cub Cadet | |
Series 7000 Tractors published in 1996, by Cub Cadet | |
Service Manual Compact Tractors (772-4207) published in 1995 | |
Series 7000 Compact Tractors published in 1996, by Cub Cadet |
