Custom C
The Custom C is a tractor produced by Custom. It is equipped with a 217.8 ci 3.6 L engine. The listed engine power is Gasoline (listed): 52 hp / 38.8 kW. Transmission: 4 forward and 1 reverse. Operating weight: 3450 lbs 1564 kg.
Engine Power
Gasoline (listed): 52 hp / 38.8 kW
Fuel & Capacities
Gasoline
Transmission
4 forward and 1 reverse
Operating Weight
3450 lbs
1564 kg
Overview
 | 1947 - 1949
Row-Crop tractor |
|---|
Production | |
|---|---|
Manufacturer | Custom |
Row-Crop tractor | |
Built in Shelbyville, Indiana, USA | |
Variants | |
|---|---|
B | tricycle front |
C | wide front |
Custom C Engine | |
|---|---|
Chrysler 3.6L 6-cyl gasoline | |
Engine details ...  |
Custom C Transmission | |
|---|---|
4-speed gear | |
Transmission details ...  |
Custom C Power | |
|---|---|
Engine | 52 hp
38.8 kW |
Plows | 2 or 3 (14-inch) |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Drum brakes | |
Open operator station. |
Power Take-off (PTO) | |
|---|---|
Rear PTO | transmission |
Dimensions & Tires | |
|---|---|
Wheelbase | 88 inches
223 cm |
Weight | 3450 lbs
1564 kg |
Front tire | 6-16 |
Rear tire | 11-28 |
Full dimensions and tires ...  | |
Belt Pulley | |
|---|---|
Diameter | 11 inches
27 cm |
Width | 7.5 inches
19 cm |
RPM | 1011 |
Speed | 2910 ft/min
886.97 meters/min |
References | |
|---|---|
 | |
Orphan Tractors by Bill Vossler |
Engine
Engine Detail — 217.8 ci / 3.6 L Gasoline
Manufacturer | Chrysler IND 5 |
Fuel Type | Gasoline |
Configuration | 6-cylinder, liquid-cooled |
Displacement | 217.8 ci
3.6 L |
Bore/Stroke | 3.25x4.375 inches
83 x 111 mm |
Power | 52 hp
38.8 kW |
Compression | 6.6:1 |
Rated RPM | 1800 |
Torque | 141 lb-ft
191.2 Nm |
Torque RPM | 1200 |
Transmission
Transmission — 4 forward and 1 reverse gear
Type | gear |
Gears | 4 forward and 1 reverse |
Dimensions
Custom C Tires | |
|---|---|
Ag front | 6-16 |
Ag rear | 11-28 |
Dimensions | |
|---|---|
Wheelbase | 88 inches
223 cm |
Length | 128 inches
325 cm |
Height | 68 inches
172 cm |
Shipping weight | 3450 lbs
1564 kg |
Photos
Custom C
Custom C
Custom C
Recommended Implements & Sizing Guide
Engineering recommendations for Custom C based on its 52 HP power envelope and ASAE agricultural standards.
| Implement & Operation | Recommended Size | Workload Rating | Engineering Notes |
|---|---|---|---|
Moldboard PlowPrimary Tillage | 2 to 3 Bottom (14-16")2 - 3 铧 (35-40 cm) | Medium Duty | Standard utility farm tillage. |
Rotary Cutter / MowerMowing & Clearing | 6 ft (72 in)1.8 m | Medium Duty | Medium pasture clearing; rear slip-clutch recommended. |
Rotary TillerSeedbed Prep | 66 to 72 in165 - 180 cm | Medium Duty | Standard utility tiller; slip clutch protection required. |
Disc HarrowSecondary Tillage | 7 to 8 ft Tandem Disc2.1 - 2.4 m 对开双排耙 | Medium Duty | Field leveling and clod breaking behind plows. |
Hay BalerHay & Forage | Small Square Baler (14x18")小方捆打捆机 (36x46 cm) | Medium Duty | Classic 2-string baler for horse and small livestock hay. |
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.
