Ford LT-10

The Ford LT-10 is a tractor produced by Ford Lawn Tractors. It is equipped with a 399 cc 24.36 ci engine. The listed engine power is Gasoline (listed): 10 hp / 7.5 kW. Transmission: 4 forward and 1 reverse. Operating weight: 490 lbs*Weight with mower deck. 222 kg.

Overview

	1990 Lawn tractor

Production
Manufacturer	Ford
Lawn tractor

Ford LT-10 Engine
10HP Briggs & Stratton 399cc 1-cyl gasoline
Fuel tank	1 gal 3.8 L
Engine details ...

Ford LT-10 Transmission
4-speed gear
Transmission details ...

Mechanical
Two-wheel drive
Manual steering
Mechanical disc brakes
Open operator station.

Dimensions & Tires
Wheelbase	49 inches 124 cm
Weight	490 lbs 222 kg
Front tire	15x6.00-6
Rear tire	18x8.50-8
Full dimensions and tires ...

Electrical
Ground	negative
Charging amps	3
Battery volts	12

References
Riding Mowers, Yard, Lawn, and Lawn & Garden Tractors published in 1990, by Ford

Engine

Engine Detail — 399 cc / 24.36 ci Gasoline

Manufacturer	Briggs & Stratton 191707
Fuel Type	Gasoline
Configuration	1-cylinder, air-cooled
Displacement	399 cc 24.36 ci
Bore/Stroke	3.44x2.62 inches 87 x 67 mm
Power	10 hp 7.5 kW
Air cleaner	dual element
Starter	electric
Starter volts	12
Oil capacity	1.1 qts 1.0 L

Transmission

Transmission — 4 forward and 1 reverse belt-driven gear

Type	belt-driven gear
Gears	4 forward and 1 reverse
Oil capacity	1.1 qts 1.0 L

Dimensions

Ford LT-10 Tires
Lawn/turf front	15x6.00-6
Lawn/turf rear	18x8.50-8

Dimensions
Wheelbase	49 inches 124 cm
Length	69 inches 175 cm
Height (steering wheel)	40 inches 101 cm
Weight	490 lbs*Weight with mower deck. 222 kg
Ground clearance	6 inches 15 cm

Attachments

Attachment overview
38" mid-mount mower deck
Snowblower

38" Mower deck
Type	mid-mount Ford
	manual lift
Cutting width	38 inches 96 cm
Overall width	47 inches 119 cm
Cut height	1.6 to 3.6 inch 4 to 9 cm

Photos

Ford LT-10 tractor photo
