Ford LT-10A
The Ford LT-10A is a tractor produced by Ford Lawn Tractors. It is equipped with a 361 cc 22.04 ci engine. The listed engine power is Gasoline (gross): 10 hp / 7.5 kW. Operating weight: 490 lbs 222 kg.
Engine Power
Gasoline (gross): 10 hp / 7.5 kW
Fuel & Capacities
Gasoline
Operating Weight
490 lbs
222 kg
Overview
 | 1991 - 1993
Lawn tractor |
|---|
Production | |
|---|---|
Manufacturer | Ford |
Lawn tractor | |
Ford LT-10A Engine | |
|---|---|
10HP Briggs & Stratton 361cc 1-cyl gasoline | |
Engine details ...  |
Ford LT-10A Transmission | |
|---|---|
gear | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Steering | manual |
Open operator station. | |
Dimensions & Tires | |
|---|---|
Weight | 490 lbs
222 kg |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
The Leisure Pleasers published in 1991, by Ford |
Engine
Engine Detail — 361 cc / 22.04 ci Gasoline
Manufacturer | Briggs & Stratton 220000 |
Fuel Type | Gasoline |
Configuration | 1-cylinder, air-cooled vertical-shaft |
Displacement | 361 cc
22.04 ci |
Bore/Stroke | 3.438x2.375 inches
87 x 60 mm |
Power (gross) | 10 hp
7.5 kW |
Starter | electric |
Starter volts | 12 |
Transmission
Transmission — gear
Type | gear |
Dimensions
Ford LT-10A Tires |
|---|
Dimensions | |
|---|---|
Weight | 490 lbs
222 kg |
Attachments
38" Mower deck | |
|---|---|
Type | mid-mount Ford |
Cutting width | 38 inches
96 cm |
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Ford Lawn Tractors Ford LT-10A.
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Ford Lawn Tractors Ford LT-10A Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Ford Lawn Tractors Ford LT-10A.
Converted Equivalents:
Horsepower (HP)10 hp
Kilowatts (kW)7.5 kW
Metric Horsepower (PS / CV)10.1 PS
