Ford RMT 526
The Ford RMT 526 is a tractor produced by Ford Lawn Tractors. It is equipped with a 206 cc 12.57 ci engine. The rated power output is 5 hp 3.7 kW. Transmission: 5 forward and 1 reverse. Operating weight: 265 lbs 120 kg.
Engine Power
5 hp
3.7 kW
Fuel & Capacities
0.5 gal
1.9 L
Transmission
5 forward and 1 reverse
Operating Weight
265 lbs
120 kg
Ford Lawn Tractors Ford RMT 526 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1977 - 1980
Riding lawn mower |
|---|---|
1977 - 1980 | |
Riding lawn mower | |
1977 - 1980 | |
|---|---|
Riding lawn mower |
Production | |
|---|---|
Manufacturer | Ford |
Riding lawn mower | |
Ford RMT 526 Engine | |
|---|---|
5HP Briggs & Stratton 206cc 1-cyl gasoline | |
Fuel tank | 0.5 gal
1.9 L |
Engine details ...  | |
Ford RMT 526 Transmission | |
|---|---|
5-speed | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Open operator station. |
Dimensions & Tires | |
|---|---|
Wheelbase | 39.75 inches
100 cm |
Weight | 265 lbs
120 kg |
Front tire | 10.25x3.50 |
Rear tire | 13x5.00-6 |
Full dimensions and tires ...  | |
References | |
|---|---|
 | |
Riding Mowers published in 1978, by Ford |
Engine
| 1977 - 1980
Riding lawn mower |
|---|---|
1977 - 1980 | |
Riding lawn mower | |
1977 - 1980 | |
|---|---|
Riding lawn mower |
Engine Detail — 206 cc / 12.57 ci Gasoline
Manufacturer | Briggs & Stratton 130902 |
Fuel Type | Gasoline |
Configuration | 1-cylinder, air-cooled vertical-shaft |
Displacement | 206 cc
12.57 ci |
Bore/Stroke | 2.56x2.44 inches
65 x 62 mm |
Power | 5 hp
3.7 kW |
Starter type | manual recoil |
Transmission
| 1977 - 1980
Riding lawn mower |
|---|---|
1977 - 1980 | |
Riding lawn mower | |
1977 - 1980 | |
|---|---|
Riding lawn mower |
Transmission — 5 forward and 1 reverse
Gears | 5 forward and 1 reverse |
 | |
Dimensions
| 1977 - 1980
Riding lawn mower |
|---|---|
1977 - 1980 | |
Riding lawn mower | |
1977 - 1980 | |
|---|---|
Riding lawn mower |
Ford RMT 526 Tires | |
|---|---|
Lawn/turf front | 10.25x3.50 |
Lawn/turf rear | 13x5.00-6 |
Dimensions | |
|---|---|
Wheelbase | 39.75 inches
100 cm |
Length | 56 inches
142 cm |
Width | 29.75 inches
75 cm |
Height (steering wheel) | 36 inches
91 cm |
Shipping weight | 265 lbs
120 kg |
Attachments
| 1977 - 1980
Riding lawn mower |
|---|---|
1977 - 1980 | |
Riding lawn mower | |
1977 - 1980 | |
|---|---|
Riding lawn mower |
26" Mower deck | |
|---|---|
Type | mid-mount Ford |
1-blade with manual lift | |
Cutting width | 26 inches
66 cm |
Overall width | 37.5 inches
95 cm |
Cut height | 0.75 to 3.25 inch
1 to 8 cm |
Cut positions | 5 |
