homelite lawn tractors t 15
 | 1972
Garden tractorAllis-Chalmers built | 1972 | Garden tractor | Allis-Chalmers built |
|---|---|---|---|---|
1972 | ||||
Garden tractor | ||||
Allis-Chalmers built | ||||
1972 | |
|---|---|
Garden tractor | |
Allis-Chalmers built |
Production | |
|---|---|
Distributor | Homelite (a part of Textron) |
Manufacturer | Allis-Chalmers |
Garden tractor | |
Homelite T-15 Engine | |
|---|---|
15HP Briggs & Stratton 531cc 1-cyl gasoline | |
Fuel tank | 2.5 gal
9.5 L |
Engine details ...  | |
Homelite T-15 Transmission | |
|---|---|
hydrostatic | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Open operator station. |
Tractor hitch | |
|---|---|
Type | sleeve hitch OptOptional |
Power Take-off (PTO) | |
|---|---|
Front PTO | independent |
Clutch | electric |
Dimensions & Tires | |
|---|---|
Weight | 900 lbs
408 kg |
Front tire | 16x6.50-8 |
Rear tire | 23x10.50-12 |
Full dimensions and tires ...  | |
Homelite T-15 attachments | |
|---|---|
42" mid-mount mower deck | |
48" mid-mount mower deck | |
snowblower | |
blade | |
Attachment details ...  |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
Homelite Lawn & Garden Equipment published in 1972 | |
Hydrostatic Drive Owners Manual published in 1973 |
