International Harvester 475

The International Harvester 475 is a tractor produced by International Harvester. It is equipped with a 212 ci 3.5 L engine. The rated power output is 60 hp 44.7 kW. Transmission: Torque Amplifier. Operating weight: 5733 lbs 2600 kg.

Overview

	1974 - 1977 Utility tractor
1974 - 1977
Utility tractor

Production
Manufacturer	International Harvester
Utility tractor
Built in Doncaster, England

International Harvester 475 Engine
Perkins 3.5L 4-cyl diesel
Fuel tank	20.3 gal 76.8 L
Engine details ...

International Harvester 475 Power
Engine	60 hp 44.7 kW
PTO (claimed)	49 hp 36.5 kW

Mechanical
Two-wheel drive
Final drives	planetary
Differential lock	mechanical rear
Power steering
Wet disc brakes
Open operator station. Four-post ROPS and cab available.

Hydraulics
Pump flow	11.9 gpm 45.0 lpm

Tractor hitch
Rear Type	II/I
Control	position and draft control
Rear lift	3969 lbs 1800 kg

Power Take-off (PTO)
Rear PTO	independent
Clutch	hydraulic wet disc
Rear PTO Type	540/1000

Dimensions & Tires
Wheelbase	84.5 inches 214 cm
Weight	5733 lbs 2600 kg
Front tire	6.00-16
Rear tire	12.4/11-36
Full dimensions and tires ...

Electrical
Charging system	alternator
Charging amps	28
Battery volts	12
Battery AH	95

Engine

Engine Detail — 212 ci / 3.5 L Diesel

Manufacturer	Perkins A4.212
Fuel Type	Diesel
Configuration	4-cylinder, liquid-cooled
Displacement	212 ci 3.5 L
Bore/Stroke	3.875x4.50 inches 98 x 114 mm
Power	60 hp 44.7 kW
Rated RPM	2300
Starter volts	12

Transmission

Transmission options
8-speed partially synchronized
16-speed two-speed power shift

Transmission — 8 forward and 4 reverse partially synchronized

Type	partially synchronized
Gears	8 forward and 4 reverse
Four synchronized gears (1-4) in low, high, and reverse ranges.
With 16.9x30 rear tires.

Transmission — Torque Amplifier

Transmission	Torque Amplifier
Type	two-speed power shift
Gears	16 forward and 8 reverse
With 16.9x30 rear tires.

Dimensions

International Harvester 475 Tires
Ag front	6.00-16
Ag rear	12.4/11-36
Ag front	7.50-16
Ag rear	14.9/13-28
	14.9/13-30
	16.9/14-30
	12.4/11-32
	13.6/12-36

Dimensions
Wheelbase	84.5 inches 214 cm
Length	128 inches 325 cm
Width	64 inches 162 cm
Height (steering wheel)	59.5 inches 151 cm
Height (cab)	90 inches 228 cm
Weight	5733 lbs 2600 kg
Front tread	52 to 80 inches 132 to 203 cm
Rear tread	52 to 76 inches 132 to 193 cm

Photos

International 475 tractor.

International 475 tractor.

International 475 operator station and controls.
