International Harvester B-614

The International Harvester B-614 is a tractor produced by International Harvester. It is equipped with a 281 ci 4.6 L engine. The rated power output is 62.5 hp 46.6 kW. Transmission: 8 forward and 2 reverse. Operating weight: 6188 lbs 2806 kg.

Overview

	1963 - 1968 Standard-tread tractor
1963 - 1968
Standard-tread tractor

Production
Manufacturer	International Harvester
Standard-tread tractor
Built in Doncaster, England
Total built	3,947

International Harvester B-614 Engine
International Harvester 4.6L 4-cyl diesel
Engine details ...

International Harvester B-614 Transmission
8-speed gear
Transmission details ...

International Harvester B-614 Power
Engine	62.5 hp 46.6 kW
Drawbar (claimed)	52 hp 38.8 kW
PTO (claimed)	55 hp 41.0 kW

Mechanical
Two- or four-wheel drive
Manual steering
Disc brakes
Open operator station.

Capacity
Fuel	20.4 gal 77.2 L
Hydraulic system	4.2 gal 15.9 L

Hydraulics
Type	open center
Capacity	4.2 gal 15.9 L
Pressure	2000 psi 137.9 bar
Pump flow	7.2 gpm 27.3 lpm

Tractor hitch
Rear Type	II
Rear lift (at ends)	3700 lbs 1678 kg

Power Take-off (PTO)
Rear PTO	transmission
	independent OptOptional
Rear PTO Type	540 (1.375)
Engine RPM	540@1150

Dimensions & Tires
Weight	6188 lbs 2806 kg
Front tire	7.50-16
Rear tire	12-38
Full dimensions and tires ...

Electrical
Charging system	generator
Batteries	2
Battery volts	6

References
International 1917-1961 Vintage Tractor Special by Allen Condie*
The Roar of Dust and Diesel - A Story of International Harvester Doncaster by Mike Teanby
World Wide Farm Equipment Buyer's Guide published in 1968, by International Harvester*
McCormick B-614 Tractor published in 1965, by International Harvester
*Publication contains known errors.

Engine

Engine Detail — 281 ci / 4.6 L Diesel

Manufacturer	International Harvester BD-281
Fuel Type	Diesel
Configuration	4-cylinder, liquid-cooled
Displacement	281 ci 4.6 L
Bore/Stroke	4.135x5.25 inches 105 x 133 mm
Power	62.5 hp 46.6 kW
Rated RPM	1600
Torque	225 lb-ft 305.1 Nm
Torque RPM	1200
Starter	electric
Starter volts	12

International Harvester B-614 Engine

Transmission

Transmission — 8 forward and 2 reverse gear

Type	gear
Gears	8 forward and 2 reverse
Clutch	dry disc
With 12.00-38 rear tires.

Dimensions

International Harvester B-614 Tires
Ag front	7.50-16
Ag rear	12-38
Ag front	6-16
	6-19
Ag rear	11-38
	14-30
	15-30

Dimensions
Length	139 inches 353 cm
Height (steering wheel)	68 inches 172 cm
Operating weight	6188 lbs 2806 kg
Ground clearance	16.75 inches 42 cm
Front tread	51.75 to 61 inches 131 to 154 cm
Front tread	52 to 76 inches 132 to 193 cm
Rear tread	52 to 72 inches 132 to 182 cm
Rear tread	52 to 88 inches 132 to 223 cm
