Iseki TU147
The Iseki TU147 is a tractor produced by Iseki. It is equipped with a 51.8 ci 0.8 L engine. The rated power output is 14.3 hp 10.7 kW. Transmission: 6 forward and 2 reverse. Operating weight: 1345 to 1444 pounds.
Overview
 | 1989 - 1992
Landhope TU7 SeriesCompact Utility tractor |
|---|---|
1989 - 1992 | |
Landhope TU7 Series | |
Compact Utility tractor | |
1989 - 1992 | |
|---|---|
Landhope TU7 Series | |
Compact Utility tractor |
Production | |
|---|---|
Manufacturer | Iseki |
Compact Utility tractor | |
Variants | |
|---|---|
TU147F | 4WD |
Iseki TU147 Engine | |
|---|---|
Mitsubishi 0.8L 3-cyl diesel | |
Fuel tank | 4.2 gal
15.9 L |
Engine details ...  | |
Iseki TU147 Transmission | |
|---|---|
6-speed gear | |
Transmission details ...  |
Iseki TU147 Power | |
|---|---|
Engine | 14.3 hp
10.7 kW |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Open operator station. |
Power Take-off (PTO) | |
|---|---|
Rear PTO Type | 540 (1.375) |
Engine RPM | 541@2500 |
735@2500 | |
1188@2500 | |
Dimensions & Tires | |
|---|---|
Wheelbase | 49.6 inches
125 cm |
Weight | 1345 to 1444 pounds |
Front tire | 4.50-10 |
2WD Rear tire | 8-16 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
Landhope TU147 TU157 TU167 TU177 published in 1991, by Iseki | |
Landhope 147 157 167 177 (1575-913-003-0) |
Engine
| 1989 - 1992
Landhope TU7 SeriesCompact Utility tractor |
|---|---|
1989 - 1992 | |
Landhope TU7 Series | |
Compact Utility tractor | |
1989 - 1992 | |
|---|---|
Landhope TU7 Series | |
Compact Utility tractor |
Engine Detail | |
|---|---|
Mitsubishi K3B | |
diesel | |
3-cylinder | |
liquid-cooled | |
Displacement | 51.8 ci
0.8 L |
Bore/Stroke | 2.67x3.07 inches
68 x 78 mm |
Power | 14.3 hp
10.7 kW |
Rated RPM | 2500 |
Starter | electric |
Starter volts | 12 |
Coolant capacity | 5.8 qts
5.5 L |
Engine Oil | |
|---|---|
 | |
Oil capacity | 2.9 qts
2.7 L |
Transmission
| 1989 - 1992
Landhope TU7 SeriesCompact Utility tractor |
|---|---|
1989 - 1992 | |
Landhope TU7 Series | |
Compact Utility tractor | |
1989 - 1992 | |
|---|---|
Landhope TU7 Series | |
Compact Utility tractor |
Transmission | |
|---|---|
Type | gear |
Gears | 6 forward and 2 reverse |
Oil capacity | 12.7 qts
12.0 L |
Three gears, plus reverse, in two ranges. | |
Speeds | |
|---|---|
 |
Dimensions
| 1989 - 1992
Landhope TU7 SeriesCompact Utility tractor |
|---|---|
1989 - 1992 | |
Landhope TU7 Series | |
Compact Utility tractor | |
1989 - 1992 | |
|---|---|
Landhope TU7 Series | |
Compact Utility tractor |
Iseki TU147 Tires | |
|---|---|
2WD Standard tires (ag) | Front: 4.50-10. Rear: 8-16 |
4WD Standard tires (ag) | Front: 5.00-12. Rear: 8-16 |
Dimensions | |
|---|---|
Wheelbase | 49.6 inches
125 cm |
Length | 85.8 inches
217 cm |
Width | 40.9 inches
103 cm |
Height | 52 inches
132 cm |
2WD Weight | 1345 lbs
610 kg |
4WD Weight | 1444 lbs
654 kg |
Ground clearance | 9.8 inches
24 cm |
2WD Front tread | 29.9/31.5 inches
75/80 cm |
4WD Front tread | 32.7 inches
83 cm |
Rear tread | 31.5 to 35.8 inches
80 to 90 cm |
