Iseki TU1501

The Iseki TU1501 is a tractor produced by Iseki. It is equipped with a 51.8 ci 0.8 L engine. The rated power output is 14.7 hp 11.0 kW. Transmission: 6 forward and 2 reverse. Operating weight: 1157 to 1235 pounds.

Overview

	1984 - ???? TU-01 SeriesCompact Utility tractor
1984 - ????
TU-01 Series
Compact Utility tractor

1984 - ????
TU-01 Series
Compact Utility tractor

Production
Manufacturer	Iseki
Compact Utility tractor

Variants
TU1501F	4WD

Iseki TU1501 Engine
Mitsubishi 0.8L 3-cyl diesel
Fuel tank	4.4 gal 16.7 L
Engine details ...

Iseki TU1501 Transmission
6-speed gear
Transmission details ...

Iseki TU1501 Power
Engine	14.7 hp 11.0 kW

Mechanical
Two- or four-wheel drive

Tractor hitch
Rear Type	JIS0

Power Take-off (PTO)
Rear PTO Type	540 (1.375)
Engine RPM	513@2600
	759@2600
	1229@2600

Dimensions & Tires
Wheelbase	48.8 inches 123 cm
Weight	1157 to 1235 pounds
Front tire	4.50-10
2WD Rear tire	8-18
Full dimensions and tires ...

Electrical
Ground	negative
Battery volts	12

References
Gold Series published in 1984, by Iseki
TU 1401 1501 1601

Engine

	1984 - ???? TU-01 SeriesCompact Utility tractor
1984 - ????
TU-01 Series
Compact Utility tractor

1984 - ????
TU-01 Series
Compact Utility tractor

Engine Detail
Mitsubishi K3B
diesel
3-cylinder
liquid-cooled
Displacement	51.8 ci 0.8 L
Bore/Stroke	2.67x3.07 inches 68 x 78 mm
Power	14.7 hp 11.0 kW
Rated RPM	2600
Starter	electric
Starter volts	12
Coolant capacity	17.4 qts 16.5 L

Engine Oil
Oil capacity	3.2 qts 3.0 L

Transmission

	1984 - ???? TU-01 SeriesCompact Utility tractor
1984 - ????
TU-01 Series
Compact Utility tractor

1984 - ????
TU-01 Series
Compact Utility tractor

Transmission
Type	gear
Gears	6 forward and 2 reverse
Oil capacity	12.7 qts 12.0 L

Speeds

Dimensions

	1984 - ???? TU-01 SeriesCompact Utility tractor
1984 - ????
TU-01 Series
Compact Utility tractor

1984 - ????
TU-01 Series
Compact Utility tractor

Iseki TU1501 Tires
2WD Standard tires (ag)	Front: 4.50-10. Rear: 8-18
4WD Standard tires (ag)	Front: 5.00-12. Rear: 8-18

Dimensions
Wheelbase	48.8 inches 123 cm
Length	83.9 inches 213 cm
Width	40.9 inches 103 cm
Height (exhaust)	66.9 inches 169 cm
2WD Weight	1157 lbs 524 kg
4WD Weight	1235 lbs 560 kg
2WD Ground clearance	11.2 inches 28 cm
4WD Ground clearance	9.7 inches 24 cm
2WD Front tread	27.6/31.5 inches 70/80 cm
4WD Front tread	30.3 inches 76 cm
Rear tread	31.5/35.8 inches 80/90 cm

Photos

Iseki TU1501 tractor photo
