Iseki TX145

The Iseki TX145 is a tractor produced by Iseki. It is equipped with a 47.4 ci 0.8 L engine. The listed engine power is Diesel (listed): 13.8 hp / 10.3 kW. Transmission: 6 forward and 2 reverse. Operating weight: 1124 lbs 509 kg.

Engine Power
Diesel (listed): 13.8 hp / 10.3 kW
Fuel & Capacities
3.2 gal 12.1 L
Transmission
6 forward and 2 reverse
Operating Weight
1124 lbs 509 kg

Overview

Iseki TX145 tractor photo
Sub-Compact Utility tractor
Sub-Compact Utility tractor
Production
Manufacturer
Iseki
Sub-Compact Utility tractor
Built in Japan
Iseki TX145 Engine
Mitsubishi 0.8L 3-cyl diesel
Fuel tank
3.2 gal 12.1 L
Engine details ...
Iseki TX145 Transmission
6-speed gear
Transmission details ...
Iseki TX145 Power
Engine
13.8 hp 10.3 kW
Mechanical
Four-wheel drive
Open operator station.
Tractor hitch
Rear Type
I
Power Take-off (PTO)
Rear PTO Type
540 (1.375)
Engine RPM
454@2600
724@2600
1185@2800
Dimensions & Tires
Wheelbase
50.4 inches 128 cm
Weight
1124 lbs 509 kg
Front tire
5.00-12
Rear tire
8-16
Full dimensions and tires ...
References
TX145 references literature
TX 145F/155F published by Iseki

Engine

Engine Detail — 47.4 ci / 0.8 L Diesel

Manufacturer
Mitsubishi K3A
Fuel Type
Diesel
Configuration
3-cylinder, liquid-cooled
Displacement
47.4 ci 0.8 L
Bore/Stroke
2.56x3.07 inches 65 x 78 mm
Power
13.8 hp 10.3 kW
Rated RPM
2600
Starter
electric
Starter volts
12

Transmission

Transmission — 6 forward and 2 reverse gear

Type
gear
Gears
6 forward and 2 reverse
Three gears (1-3), plus reverse (R) in two ranges (low/high).
TX145 gear speeds

Dimensions

Iseki TX145 Tires
Ag front
5.00-12
Ag rear
8-16
Dimensions
Wheelbase
50.4 inches 128 cm
Length
77.8 inches 197 cm
Width
46.5 inches 118 cm
Height
47.2 inches 119 cm
Weight
1124 lbs 509 kg
Ground clearance
9.8 inches 24 cm
Front tread
31.5 inches 80 cm
Rear tread
30.3/37 inches 76/93 cm

Photos

Iseki TX145, left side.

Iseki TX145, left side.

Iseki TX145, right side.

Iseki TX145, right side.

Fluids, Capacities & Working Autonomy

Standard fluid requirements, service intervals, and continuous runtime estimates for Iseki TX145.

Estimated Continuous Field Runtime: 4.5 hrs

Approximately 4.5 hours of continuous field operation at ~75% rated power on a full tank (3.2 gal / 12.1 L).

Estimated 75% Load Fuel Burn~0.7 gal/hr (2.7 L/hr)

Engine Crankcase Oil

SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours

Transmission & Hydraulic System

UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours

Engine Cooling System

50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours

Iseki TX145 Specification Unit Converter

Convert power, fluid capacities, and operating weights between metric and imperial standards for Iseki TX145.

Converted Equivalents:

Horsepower (HP)13.8 hp
Kilowatts (kW)10.3 kW
Metric Horsepower (PS / CV)14 PS
