john deere 3520
 | 2005 - 2013
3000 Twenty SeriesCompact Utility tractor | 2005 - 2013 | 3000 Twenty Series | Compact Utility tractor |
|---|---|---|---|---|
2005 - 2013 | ||||
3000 Twenty Series | ||||
Compact Utility tractor | ||||
2005 - 2013 | |
|---|---|
3000 Twenty Series | |
Compact Utility tractor |
Production | |
|---|---|
Manufacturer | John Deere |
Compact Utility tractor | |
Built in Augusta, Georgia, USA | |
John Deere 3520 Engine | |
|---|---|
Yanmar 1.5L 3-cyl diesel | |
Engine details ...  |
John Deere 3520 Transmissions | |
|---|---|
12-speed partially synchronized with power shuttle | |
hydrostatic | |
Transmission details ...  |
John Deere 3520 Power | |
|---|---|
Engine | 37 hp
27.6 kW |
PTO (claimed) | 30 hp
22.4 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Steering | power |
Wet disc brakes | |
Two-post foldable ROPS. Cab optional. | |
Photos | |
|---|---|
 | |
John Deere 3520 photos...  |
Capacity | |
|---|---|
ROPS Fuel | 13.5 gal
51.1 L |
Cab Fuel | 11.8 gal
44.7 L |
Hydraulic system | 6.8 gal
25.7 L |
| 6.3 gal (with gear transmission)
23.8 L |
Hydraulics | |
|---|---|
Type | open center |
Capacity | 6.8 gal
25.7 L |
| 6.3 gal (with gear transmission)
23.8 L |
Valves | 5 |
Pump flow | 8.6 gpm
32.6 lpm |
Total flow | 13.9 gpm
52.6 lpm |
Tractor hitch | |
|---|---|
Rear Type | I |
Rear lift | 2530 lbs
1147 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540 |
Mid PTO | optional |
Mid PTO Type | 2100 |
Dimensions & Tires | |
|---|---|
Wheelbase | 68 inches
172 cm |
Weight | 2900 to 3570 pounds |
Front tire | 7-14 |
Rear tire | 11.2-24 |
Full dimensions and tires ...  | |
John Deere 3520 attachments | |
|---|---|
60" mid-mount mower deck | |
front-end loader | |
backhoe | |
Attachment details ...  |
3520 Serial Numbers | |
|---|---|
2005 | 100001 (hydrostatic) |
2006 | 258001 (hydrostatic) |
2007 | 358001 (hydrostatic) |
2008 | 450001 (hydrostatic) |
2009 | 512001 (hydrostatic) |
2010 | 612001 (hydrostatic) |
2011 | 71001 (hydrostatic) |
2012 | 740001 (hydrostatic) |
2013 | 910001 (hydrostatic) |
2005 | 100001 (gear) |
2006 | 266001 (gear) |
2007 | 366001 (gear) |
2008 | 460001 (gear) |
2009 | 514001 (gear) |
2010 | 614001 (gear) |
2011 | 710001 (gear) |
2012 | ------ |
2013 | 910001 (gear) |
FAQ: How to read a serial number table. | |
Electrical | |
|---|---|
Ground | negative |
Charging amps | 40 |
| 55 (optional) |
| 75 (with cab) |
Battery CCA | 500 |
Battery volts | 12 |
References | |
|---|---|
 | |
Commercial & Consumer Equipment Purchasing Guide published in 2007, by John Deere | |
3000 Series published in 2008, by John Deere | |
3000 Series published in 2009, by John Deere | |
3000 Twenty Series Compact Tractors published in 2005, by John Deere | |
3000 Twenty Series Tractors Product Information Handbook published in 2004, by John Deere | |
TWENTY Series Tractors published in 2010, by John Deere | |
Commercial & Consumer Equipment Purchase Guide published in 2005, by John Deere |
