John Deere CR125
The John Deere CR125 is a tractor produced by John Deere Lawn Tractors. It is equipped with a 344 cc 21 ci engine. The listed engine power is Gasoline (listed): 12.5 hp / 9.3 kW. Transmission: 5 forward and 1 reverse. Operating weight: 363.8 lbs 165 kg.
Engine Power
Gasoline (listed): 12.5 hp / 9.3 kW
Fuel & Capacities
1.06 gal
4.0 L
Transmission
5 forward and 1 reverse
Operating Weight
363.8 lbs
165 kg
Overview
 | 2004 - ????
CR SeriesRiding lawn mower |
|---|---|
2004 - ???? | |
CR Series | |
Riding lawn mower | |
2004 - ???? | |
|---|---|
CR Series | |
Riding lawn mower |
Production | |
|---|---|
Manufacturer | John Deere |
Riding lawn mower | |
John Deere CR125 Engine | |
|---|---|
9.3KW Briggs & Stratton 344cc 1-cyl gasoline | |
Fuel tank | 1.06 gal
4.0 L |
Engine details ...  | |
Mechanical | |
|---|---|
Two-wheel drive | |
Steering | manual |
Disc on transmission brakes | |
Open operator station. | |
Dimensions & Tires | |
|---|---|
Wheelbase | 44.5 inches
113 cm |
Weight | 363.8 lbs
165 kg |
Front tire | 11x4.00-4 |
Rear tire | 15x6.00-6 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
Battery AH | 18 |
References | |
|---|---|
 | |
CR/LR Series Rear Discharge Riders & Lawn Tractors published by John Deere | |
Walk Behind Mower & Lawn Tractor Range published in 2011, by John Deere | |
The Complete Range of Lawn Care Solutions published in 2014, by John Deere |
Engine
| 2004 - ????
CR SeriesRiding lawn mower |
|---|---|
2004 - ???? | |
CR Series | |
Riding lawn mower | |
2004 - ???? | |
|---|---|
CR Series | |
Riding lawn mower |
Engine Detail — 344 cc / 21 ci Gasoline
Manufacturer | Briggs & Stratton 21B807 |
Fuel Type | Gasoline |
Configuration | 1-cylinder, air-cooled vertical-shaft |
Displacement | 344 cc
21 ci |
Power | 12.5 hp
9.3 kW |
Starter | electric |
Starter volts | 12 |
Transmission
| 2004 - ????
CR SeriesRiding lawn mower |
|---|---|
2004 - ???? | |
CR Series | |
Riding lawn mower | |
2004 - ???? | |
|---|---|
CR Series | |
Riding lawn mower |
Transmission options | |
|---|---|
hydrostatic | |
5-speed gear |
Transmission — infinite forward and reverse belt-driven hydrostatic
Type | belt-driven hydrostatic |
Gears | infinite forward and reverse |
 | |
Transmission — 5 forward and 1 reverse belt-driven gear
Type | belt-driven gear |
Gears | 5 forward and 1 reverse |
 | |
Dimensions
| 2004 - ????
CR SeriesRiding lawn mower |
|---|---|
2004 - ???? | |
CR Series | |
Riding lawn mower | |
2004 - ???? | |
|---|---|
CR Series | |
Riding lawn mower |
John Deere CR125 Tires | |
|---|---|
Lawn/turf front | 11x4.00-4 |
Lawn/turf rear | 15x6.00-6 |
Dimensions | |
|---|---|
Wheelbase | 44.5 inches
113 cm |
Length | 73.4 inches
186 cm |
Width | 29.9 inches
75 cm |
Height (steering wheel) | 43.3 inches
109 cm |
Weight | 363.8 lbs
165 kg |
Attachments
| 2004 - ????
CR SeriesRiding lawn mower |
|---|---|
2004 - ???? | |
CR Series | |
Riding lawn mower | |
2004 - ???? | |
|---|---|
CR Series | |
Riding lawn mower |
28.35" Mower deck | |
|---|---|
Type | mid-mount John Deere |
Cutting width | 28.35 inches
72 cm |
Cut height | 1.18 to 3.15 inch
2 to 8 cm |
Photos
John Deere CR125 tractor photo
John Deere Lawn Tractors John Deere CR125 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for John Deere Lawn Tractors John Deere CR125.
Converted Equivalents:
Horsepower (HP)12.5 hp
Kilowatts (kW)9.3 kW
Metric Horsepower (PS / CV)12.7 PS
