john deere lawn tractors r70
 | 1984 - 1986
Riding lawn mower | 1984 - 1986 | Riding lawn mower |
|---|---|---|---|
1984 - 1986 | |||
Riding lawn mower | |||
1984 - 1986 | |
|---|---|
Riding lawn mower |
Production | |
|---|---|
Manufacturer | John Deere |
Riding lawn mower | |
Original price was $1,199 in 1983 | |
John Deere R70 Engine | |
|---|---|
8HP Briggs & Stratton 1-cyl gasoline | |
Fuel tank | 1.25 gal
4.7 L |
Engine details ...  | |
John Deere R70 Transmission | |
|---|---|
5-speed gear | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Steering | manual |
Mechanical band brakes | |
Open operator station | |
Photos | |
|---|---|
 | |
John Deere R70 photos...  |
Power Take-off (PTO) | |
|---|---|
Mid PTO | independent |
Clutch | mechanical |
Dimensions & Tires | |
|---|---|
Wheelbase | 42 inches
106 cm |
Weight | 275 lbs
124 kg |
Front tire | 11x4.00-5 |
Rear tire | 16x6.50-8 |
Full dimensions and tires ...  | |
John Deere R70 attachments | |
|---|---|
30" mid-mount mower deck | |
Attachment details ...  |
R70 Serial Numbers | |
|---|---|
Location: | Serial number plate on the left rear of the mower, near the hitch. |
References | |
|---|---|
 | |
Riding Mowers & Lawn Tractors published in 1985, by John Deere | |
John Deere Lawn Tractors and Riding Mowers published in 1986 | |
Operator's Manual R70, R72, R92, S82, and S92 Riding Mowers (OM-M88160) published in 1985 | |
Consumer Products Price List published in 1983, by John Deere | |
Grounds Care Equipment Purchasing Guide published in 1983, by John Deere |
