kubota kl380
 | 2006 - 2007
KL SeriesCompact Utility tractor | 2006 - 2007 | KL Series | Compact Utility tractor |
|---|---|---|---|---|
2006 - 2007 | ||||
KL Series | ||||
Compact Utility tractor | ||||
2006 - 2007 | |
|---|---|
KL Series | |
Compact Utility tractor |
Production | |
|---|---|
Manufacturer | Kubota |
Compact Utility tractor | |
Kubota KL380 Engine | |
|---|---|
Kubota 2.2L 4-cyl diesel | |
Fuel tank | 10.6 gal
40.1 L |
Engine details ...  | |
Kubota KL380 Transmissions | |
|---|---|
20-speed | |
30-speed | |
Transmission details ...  |
Kubota KL380 Power | |
|---|---|
Engine | 37.4 hp
27.9 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Power steering | |
Mechanical wet disc brakes | |
Two-post ROPS. Cab optional. |
Tractor hitch | |
|---|---|
Rear Type | I |
Power Take-off (PTO) | |
|---|---|
Rear PTO Type | 540 (1.375) |
Engine RPM | 540@2600 |
| 762@2600 |
| 944@2600 |
| 1258@2600 |
| -944@2600 |
Dimensions & Tires | |
|---|---|
Wheelbase | 74.4 inches
188 cm |
Weight | 3351 to 3748 pounds |
Front tire | 8-18 |
Rear tire | 12.4-28 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
