Kubota KL550 Hi-Speed

The Kubota KL550 Hi-Speed is a tractor produced by Kubota. It is equipped with a 148.5 ci 2.4 L engine. The rated power output is 54.3 hp 40.5 kW. Transmission: 30 forward and 20 reverse. Operating weight: 4079 lbs 1850 kg.

Overview

	2006 - 2007 KL SeriesCompact Utility tractor
2006 - 2007
KL Series
Compact Utility tractor

Production
Manufacturer	Kubota
Compact Utility tractor

Kubota KL550 Engine
Kubota 2.4L 4-cyl diesel
Fuel tank	12.4 gal 46.9 L
Engine details ...

Kubota KL550 Transmission
30-speed
Transmission details ...

Kubota KL550 Power
Engine	54.3 hp 40.5 kW

Mechanical
Four-wheel drive
Power steering
Mechanical wet disc brakes
Cab standard.

Tractor hitch
Rear Type	I

Power Take-off (PTO)
Rear PTO Type	540 (1.375)
Engine RPM	545@2700
	769@2700
	952@2700
	1270@2700
	-952@2700

Dimensions & Tires
Wheelbase	76.4 inches 194 cm
Weight	4079 lbs 1850 kg
Front tire	8.3-20
Rear tire	12.4-32
Full dimensions and tires ...

Electrical
Ground	negative
Battery volts	12

Engine

Engine Detail — 148.5 ci / 2.4 L Diesel

Manufacturer	Kubota V2403
Fuel Type	Diesel
Configuration	4-cylinder, liquid-cooled
Displacement	148.5 ci 2.4 L
Bore/Stroke	3.43x4.03 inches 87 x 102 mm
Power	54.3 hp 40.5 kW
Rated RPM	2700
Starter	electric
Starter volts	12

Transmission

Transmission — 30 forward and 20 reverse

Gears	30 forward and 20 reverse
Twelve gears in three ranges (creeper, medium, and high-speed) with shuttle shift. Only gears 1-8 available in reverse. In high-speed range only gears six forward and four reverse gears available.

Dimensions

Kubota KL550 Tires
Standard tires (ag)	Front: 8.3-20. Rear: 12.4-32

Dimensions
Wheelbase	76.4 inches 194 cm
Length	139.8 inches 355 cm
Width	60.4 inches 153 cm
Height (cab)	87.4 inches 221 cm
Weight	4079 lbs 1850 kg
Ground clearance	17.3 inches 43 cm
Front tread	47.8 inches 121 cm
Rear tread	44.5 to 60.2 inches 113 to 152 cm
