Kubota L1-325
The Kubota L1-325 is a tractor produced by Kubota. It is equipped with a 105.7 ci 1.7 L engine. The listed engine power is Diesel (listed): 31.6 hp / 23.6 kW. Transmission: 16 forward and reverse. Operating weight: 3064 lbs 1389 kg.
Engine Power
Diesel (listed): 31.6 hp / 23.6 kW
Fuel & Capacities
Diesel
Transmission
16 forward and reverse
Operating Weight
3064 lbs
1389 kg
Overview
 | 1988 - 1991
L1 SeriesCompact Utility tractor
L1 Series
Compact Utility tractor |
|---|
Production | |
|---|---|
Manufacturer | Kubota |
Compact Utility tractor | |
Kubota L1-325 Engine | |
|---|---|
Kubota 1.7L 4-cyl diesel | |
Engine details ...  |
Kubota L1-325 Transmission | |
|---|---|
16-speed | |
Transmission details ...  |
Kubota L1-325 Power | |
|---|---|
Engine | 31.6 hp
23.6 kW |
PTO (claimed) | 29.5 hp
22.0 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Two-post ROPS. |
Hydraulics | |
|---|---|
Pump flow | 6.2 gpm
23.5 lpm |
Tractor hitch | |
|---|---|
Rear Type | I |
Rear lift | 1609 lbs
729 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO Type | 634/733/1108/1350 (1.375) |
Dimensions & Tires | |
|---|---|
Wheelbase | 68.3 inches
173 cm |
Weight | 3064 lbs
1389 kg |
Front tire | 8-16 |
Rear tire | 13.6-24 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
Engine
Engine Detail — 105.7 ci / 1.7 L Diesel
Manufacturer | Kubota V1702 |
Fuel Type | Diesel |
Configuration | 4-cylinder, liquid-cooled |
Displacement | 105.7 ci
1.7 L |
Bore/Stroke | 3.1x3.6 inches
79 x 91 mm |
Power | 31.6 hp
23.6 kW |
Rated RPM | 2700 |
Starter | electric |
Starter volts | 12 |
Transmission
Transmission — 16 forward and reverse
Gears | 16 forward and reverse |
 | |
Dimensions
Kubota L1-325 Tires | |
|---|---|
Standard tires (ag) | Front: 8-16. Rear: 13.6-24 |
Dimensions | |
|---|---|
Wheelbase | 68.3 inches
173 cm |
Length | 125.2 inches
318 cm |
Width | 59.8 inches
151 cm |
Height (ROPS) | 90.9 inches
230 cm |
Weight | 3064 lbs
1389 kg |
Ground clearance | 14.2 inches
36 cm |
Front tread | 46.9 inches
119 cm |
Rear tread | 42.5 to 61 inches
107 to 154 cm |
Recommended Implements & Sizing Guide
Engineering recommendations for Kubota L1-325 based on its 31.6 HP power envelope and ASAE agricultural standards.
| Implement & Operation | Recommended Size | Workload Rating | Engineering Notes |
|---|---|---|---|
Moldboard PlowPrimary Tillage | 2 to 3 Bottom (14-16")2 - 3 铧 (35-40 cm) | Medium Duty | Standard utility farm tillage. |
Rotary Cutter / MowerMowing & Clearing | 5 ft (60 in)1.5 m | Medium Duty | Pasture maintenance and weeds up to 1.5" diameter. |
Rotary TillerSeedbed Prep | 54 to 60 in135 - 150 cm | Medium Duty | Thorough seedbed preparation in orchards and vegetable plots. |
Disc HarrowSecondary Tillage | 5 to 6 ft (16-18" discs)1.5 - 1.8 m (40-45 cm 耙片) | Light Duty | Small acreage soil break-up and secondary aeration. |
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Kubota L1-325.
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Kubota L1-325 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Kubota L1-325.
Converted Equivalents:
Horsepower (HP)31.6 hp
Kilowatts (kW)23.6 kW
Metric Horsepower (PS / CV)32 PS
