Lawn Chief 440

The Lawn Chief 440 is a tractor produced by Lawn Chief Lawn Tractors. It is equipped with a 465 cc 28.4 ci engine. The rated power output is 12 hp 8.9 kW. Transmission: Dana 4360-62. Operating weight: 415 lbs 188 kg.

Overview

	1991 - 1995 Lawn tractor
1991 - 1995
Lawn tractor

Production
Manufacturer	Lawn Chief
Lawn tractor
Built in Harvard, Illinois, USA
Original price was $1,099 in 1992

Lawn Chief 440 Engine
12HP Briggs & Stratton 465cc 1-cyl gasoline
Fuel tank	1.3 gal 4.9 L
Engine details ...

Lawn Chief 440 Transmission
5-speed gear
Transmission details ...

Mechanical
Two-wheel drive
Manual steering
Open operator station

Power Take-off (PTO)
Mid PTO	independent
Clutch	manual

Dimensions & Tires
Weight	415 lbs 188 kg
Front tire	15x6.00
Rear tire	18x9.50
Full dimensions and tires ...

Electrical
Ground	negative
Battery volts	12

References
Master Parts Manual published in 1991
Master Parts Manual published in 1992
Master Parts/Service Manual published in 1993
Master Parts/Service Manual published in 1994
Master Parts/Service Manual published in 1995

Engine

Engine Detail — 465 cc / 28.4 ci Gasoline

Manufacturer	Briggs & Stratton 283707
Fuel Type	Gasoline
Configuration	1-cylinder, air-cooled vertical-shaft
Displacement	465 cc 28.4 ci
Bore/Stroke	3.4375x3.0625 inches 87 x 78 mm
Power (gross)	12 hp 8.9 kW
Starter	electric
Starter volts	12

Transmission

Transmission — Dana 4360-62

Transmission	Dana 4360-62
Type	belt-driven gear
Gears	5 forward and 1 reverse

Dimensions

Lawn Chief 440 Tires
Lawn/turf front	15x6.00
Lawn/turf rear	18x9.50

Dimensions
Length	63 inches 160 cm
Height	37 inches 93 cm
Weight	415 lbs 188 kg

Attachments

Attachment overview
39" mid-mount mower deck
Blade

39" Mower deck
Type	mid-mount Lawn Chief
	2-blade with manual lift
Cutting width	39 inches 99 cm
Overall width	49 inches 124 cm

Photos

Lawn Chief 440 tractor photo
