massey harris no 3 15 28
 | 1922 - 1923
Standard-tread tractor | 1922 - 1923 | Standard-tread tractor |
|---|---|---|---|
1922 - 1923 | |||
Standard-tread tractor | |||
1922 - 1923 | |
|---|---|
Standard-tread tractor |
Production | |
|---|---|
Manufacturer | Massey-Harris |
Standard-tread tractor | |
Built in Weston, Ontario, Canada | |
The Massey-Harris No. 3 15-28 was based on a tractor design licensed from Parrett. | |
Massey-Harris No. 3 15-28 Engine | |
|---|---|
Waukesha 6.5L 4-cyl gasoline | |
Engine details ...  |
Massey-Harris No. 3 15-28 Transmission | |
|---|---|
2-speed gear | |
Transmission details ...  |
Massey-Harris No. 3 15-28 Power | |
|---|---|
Drawbar (claimed) | 15 hp
11.2 kW |
Belt (claimed) | 28 hp
20.9 kW |
Plows | 3 (14-inch) |
Mechanical | |
|---|---|
Two-wheel drive | |
Final drives | spur gear |
Steering | manual |
Open operator station. | |
Photos | |
|---|---|
 | |
Massey-Harris No. 3 15-28 photos...  |
Dimensions & Tires | |
|---|---|
Weight | 5800 lbs
2630 kg |
Full dimensions and tires ...  | |
No. 3 15-28 Serial Numbers | |
|---|---|
Location: | Inside right rear tractor fender. |
Belt Pulley | |
|---|---|
Diameter | 12 inches
30 cm |
Width | 7 inches
17 cm |
RPM | 1000 |
