Murray 3666

The Murray 3666 is a tractor produced by Murray Lawn Tractors. The listed engine power is Gasoline (listed): 8 hp / 6.0 kW. Transmission: 3 forward and 1 reverse. Operating weight: 462 lbs 209 kg.

Overview

	1975 - 1980 Lawn tractor
1975 - 1980
Lawn tractor

Production
Manufacturer	Murray
Lawn tractor
Built in Lawrenceburg, Tennessee, USA

Variants
LT/8	similar Sears model

Murray 3666 Engine
8HP Briggs & Stratton 1-cyl gasoline
Engine details ...

Murray 3666 Transmission
3-speed gear
Transmission details ...

Mechanical
Two-wheel drive
Manual steering
Disc brakes
Open operator station.

Power Take-off (PTO)
Mid PTO	independent
Clutch	manual

Dimensions & Tires
Weight	462 lbs 209 kg
Front tire	15x6.00
Rear tire	18x9.50
Full dimensions and tires ...

Electrical
Ground	negative
Battery volts	12

References
1976 Murray
Mowers and Tiller for 77 published in 1977, by Murray
The 1979 Murray Mowers
The 1980 Murray Mowers
Murray Parts Microfiche published in 1976
Murray Parts Microfiche published in 1977
Murray Parts Microfiche published in 1978
Murray Parts Microfiche published in 1979

Engine

Engine Detail — Gasoline

Manufacturer	Briggs & Stratton
Fuel Type	Gasoline
Configuration	1-cylinder, air-cooled vertical-shaft
Power	8 hp 6.0 kW
Starter	electric
Starter volts	12

Transmission

Transmission — 3 forward and 1 reverse belt-driven gear

Type	belt-driven gear
Gears	3 forward and 1 reverse

Dimensions

Murray 3666 Tires
Lawn/turf front	15x6.00
Lawn/turf rear	18x9.50

Dimensions
Weight	462 lbs 209 kg

Attachments

Attachment overview
36" mid-mount mower deck
Snowblower
Blade

36" Mower deck
Type	mid-mount Murray
	2-blade with manual lift
Cutting width	36 inches 91 cm
Cut height	1.5 to 3.5 inch 3 to 8 cm

Photos

Murray 3666
