Poloron 19750
The Poloron 19750 is a tractor produced by Poloron Lawn Tractors. It is equipped with a 275 cc 16.79 ci engine. The rated power output is 7 hp 5.2 kW. Transmission: 6 forward and 2 reverse. Drive type: belt.
Engine Power
7 hp
5.2 kW
Drive & Traction
belt
Fuel & Capacities
Gasoline
Transmission
6 forward and 2 reverse
Poloron Lawn Tractors Poloron 19750 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1969
Fleetwood SeriesLawn tractor |
|---|---|
1969 | |
Fleetwood Series | |
Lawn tractor | |
Production | |
|---|---|
Manufacturer | Poloron |
Lawn tractor | |
Built in Michigan City, Indiana, USA | |
Poloron 19750 Engine | |
|---|---|
7HP Briggs & Stratton 275cc 1-cyl gasoline | |
Engine details ...  |
Poloron 19750 Transmission | |
|---|---|
6-speed friction disc | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Open operator station |
Dimensions & Tires | |
|---|---|
Front tire | 14x5 |
Rear tire | 16x6.50 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Battery volts | 12 |
References | |
|---|---|
 | |
Owner's Operating Manual for Lawn Tractors Model No. 19730 19740 19752 19742 19750 (970647) published in 1969 | |
Dealer Service Guide published in 1974 |
Engine
Engine Detail — 275 cc / 16.79 ci Gasoline
Manufacturer | Briggs & Stratton 170704 |
Fuel Type | Gasoline |
Configuration | 1-cylinder, air-cooled vertical-shaft |
Displacement | 275 cc
16.79 ci |
Bore/Stroke | 3.00x2.375 inches
76 x 60 mm |
Power (gross) | 7 hp
5.2 kW |
Starter | electric |
Starter volts | 12 |
Transmission
Transmission — 6 forward and 2 reverse friction disc
Type | friction disc |
Gears | 6 forward and 2 reverse |
Dimensions
Poloron 19750 Tires | |
|---|---|
Lawn/turf front | 14x5 |
Lawn/turf rear | 16x6.50 |
Dimensions |
|---|
Attachments
Attachment overview | |
|---|---|
32" mid-mount mower deck | |
Snowblower | |
Blade |
32" Mower deck | |
|---|---|
Type | mid-mount Poloron |
2-blade | |
Cutting width | 32 inches
81 cm |
Drive | belt |
