Poloron 20511
The Poloron 20511 is a tractor produced by Poloron Lawn Tractors. It is equipped with a 206 cc 12.57 ci engine. The rated power output is 5 hp 3.7 kW. Transmission: 5 forward and 1 reverse. Drive type: belt.
Engine Power
5 hp
3.7 kW
Drive & Traction
belt
Fuel & Capacities
Gasoline
Transmission
5 forward and 1 reverse
Poloron Lawn Tractors Poloron 20511 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1971
Fleetwood SeriesLawn tractor |
|---|---|
1971 | |
Fleetwood Series | |
Lawn tractor | |
Production | |
|---|---|
Manufacturer | Poloron |
Lawn tractor | |
Built in Michigan City, Indiana, USA | |
Poloron 20511 Engine | |
|---|---|
5HP Briggs & Stratton 206cc 1-cyl gasoline | |
Engine details ...  |
Poloron 20511 Transmission | |
|---|---|
5-speed friction disc | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Open operator station |
Dimensions & Tires | |
|---|---|
Front tire | 10x2.50 |
Rear tire | 13x5.00 |
Full dimensions and tires ...  | |
References | |
|---|---|
 | |
Operating Manual Fleetwood Lawn Tractors Model Nos. 20511, 20821 & 20822 (107221) published in 1971 |
Engine
Engine Detail — 206 cc / 12.57 ci Gasoline
Manufacturer | Briggs & Stratton 130902 |
Fuel Type | Gasoline |
Configuration | 1-cylinder, air-cooled vertical-shaft |
Displacement | 206 cc
12.57 ci |
Bore/Stroke | 2.5625x2.4375 inches
65 x 62 mm |
Power (gross) | 5 hp
3.7 kW |
Starter type | manual recoil |
Transmission
Transmission — 5 forward and 1 reverse friction disc
Type | friction disc |
Gears | 5 forward and 1 reverse |
Dimensions
Poloron 20511 Tires | |
|---|---|
Lawn/turf front | 10x2.50 |
Lawn/turf rear | 13x5.00 |
Dimensions |
|---|
Attachments
Attachment overview | |
|---|---|
25" mid-mount mower deck | |
Snowblower | |
Blade |
25" Mower deck | |
|---|---|
Type | mid-mount Poloron |
1-blade | |
Cutting width | 25 inches
63 cm |
Drive | belt |
Photos
Poloron 20511 tractor photo
