Poloron 9730
The Poloron 9730 is a tractor produced by Poloron Lawn Tractors. It is equipped with a 275 cc 16.79 ci engine. The rated power output is 7 hp 5.2 kW. Transmission: 6 forward and 2 reverse. Drive type: belt.
Engine Power
7 hp
5.2 kW
Drive & Traction
belt
Fuel & Capacities
Gasoline
Transmission
6 forward and 2 reverse
Poloron Lawn Tractors Poloron 9730 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1969
Stallion SeriesLawn tractor |
|---|---|
1969 | |
Stallion Series | |
Lawn tractor | |
Production | |
|---|---|
Manufacturer | Poloron |
Lawn tractor | |
Built in Michigan City, Indiana, USA | |
Poloron 9730 Engine | |
|---|---|
7HP Briggs & Stratton 275cc 1-cyl gasoline | |
Engine details ...  |
Poloron 9730 Transmission | |
|---|---|
6-speed friction disc | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Open operator station |
Dimensions & Tires | |
|---|---|
Front tire | 13x4 |
Rear tire | 16x6.50 |
Full dimensions and tires ...  | |
References | |
|---|---|
 | |
Owner's Operating Manual for Lawn Tractors Model No. 9730 9732 9740 9742 (970646) published in 1969 | |
Dealer Service Guide published in 1974 |
Engine
Engine Detail — 275 cc / 16.79 ci Gasoline
Manufacturer | Briggs & Stratton 170702 |
Fuel Type | Gasoline |
Configuration | 1-cylinder, air-cooled vertical-shaft |
Displacement | 275 cc
16.79 ci |
Bore/Stroke | 3.00x2.375 inches
76 x 60 mm |
Power (gross) | 7 hp
5.2 kW |
Starter type | manual recoil |
Transmission
Transmission — 6 forward and 2 reverse friction disc
Type | friction disc |
Gears | 6 forward and 2 reverse |
Dimensions
Poloron 9730 Tires | |
|---|---|
Lawn/turf front | 13x4 |
Lawn/turf rear | 16x6.50 |
Dimensions |
|---|
Attachments
Attachment overview | |
|---|---|
32" mid-mount mower deck | |
Snowblower | |
Blade |
32" Mower deck | |
|---|---|
Type | mid-mount Poloron |
2-blade | |
Cutting width | 32 inches
81 cm |
Drive | belt |
