roper lawn tractors t022
 | 1973 - 1977
Garden tractor | 1973 - 1977 | Garden tractor |
|---|---|---|---|
1973 - 1977 | |||
Garden tractor | |||
1973 - 1977 | |
|---|---|
Garden tractor |
Production | |
|---|---|
Manufacturer | Roper |
Garden tractor | |
Built in Orangeburg, South Carolina, USA | |
Roper T022 Engine | |
|---|---|
10HP Tecumseh 389cc 1-cyl gasoline | |
Fuel tank | 2.5 gal
9.5 L |
Engine details ...  | |
Roper T022 Transmission | |
|---|---|
6-speed gear | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Open operator station. |
Photos | |
|---|---|
 | |
Roper T022 photos...  |
Tractor hitch | |
|---|---|
Type | Roper Tri-Hitch |
Dimensions & Tires | |
|---|---|
Wheelbase | 43 inches
109 cm |
Front tire | 16x5.00-8 |
Rear tire | 22.5x8.50-12 |
Full dimensions and tires ...  | |
Roper T022 attachments | |
|---|---|
38" mid-mount mower deck | |
snowblower | |
blade | |
Attachment details ...  |
T022 Serial Numbers | |
|---|---|
Location: | Serial number plate on top of the RT-10 frame, in front of the gear shift lever. |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
Lawn and Garden Power Equipment published in 1973, by Roper | |
Ride the Big Red Roper published in 1974 | |
Roper '76 published in 1976 | |
Garden Tractors published in 1977, by Roper | |
Garden Tractors published in 1978, by Roper | |
Parts and "We Care" Service published in 1986 | |
Service Manual Tractors & Attachments published in 1973 |
