Sears 1036 536.25094

The Sears 1036 536.25094 is a tractor produced by Sears Lawn Tractors. It is equipped with a 399 cc 24.36 ci engine. The listed engine power is Gasoline (gross): 10 hp / 7.5 kW. Transmission: 3 forward and 1 reverse. Operating weight: 405 lbs 183 kg.

Overview

	1977 - 1978 Lawn tractorWestern Tool built Lawn tractor Western Tool built

Production
Distributor	Sears
Manufacturer	Western Tool
Lawn tractor
Original price was $799 in 1977

Variants
25094	1977 gold paint
25521	1978 red/white paint

Sears 1036 Engine
10HP Briggs & Stratton 399cc 1-cyl gasoline
Fuel tank	1 gal 3.8 L
Engine details ...

Sears 1036 Transmission
3-speed gear
Transmission details ...

Mechanical
Two-wheel drive
Manual steering
Disc brakes
Open operator station.

Dimensions & Tires
Weight	405 lbs 183 kg
Front tire	15x6
Rear tire	18x9.5
Full dimensions and tires ...

Electrical
Ground	negative
Battery volts	12

References
Farm and Ranch Catalog published in 1977, by Sears*
Spring/Summer Catalog published in 1978, by Sears
*Publication contains known errors.

Engine

Engine Detail — 399 cc / 24.36 ci Gasoline

Manufacturer	Briggs & Stratton 251707
Fuel Type	Gasoline
Configuration	1-cylinder, air-cooled vertical-shaft
Displacement	399 cc 24.36 ci
Bore/Stroke	3.44x2.625 inches 87 x 67 mm
Power (gross)	10 hp 7.5 kW
Starter	electric
Starter volts	12

Transmission

Transmission — 3 forward and 1 reverse belt-driven gear

Type	belt-driven gear
Gears	3 forward and 1 reverse

Dimensions

Sears 1036 Tires
Lawn/turf front	15x6
Lawn/turf rear	18x9.5

Dimensions
Length	64 inches 162 cm
Height	40 inches 101 cm
Shipping weight	405 lbs 183 kg

Attachments

36" Mower deck
Type	mid-mount Sears
	2-blade with manual lift
Cutting width	36 inches 91 cm
Overall width	36 inches 91 cm
Cut height	1.5 to 3.5 inch 3 to 8 cm
Cut positions	5

Photos

Sears 1036 536.25094 tractor photo
