Snapper 30106
The Snapper 30106 is a tractor produced by Snapper Lawn Tractors. The listed engine power is Gasoline (gross): 10 hp / 7.5 kW. Transmission: 5 forward and reverse.
Engine Power
Gasoline (gross): 10 hp / 7.5 kW
Fuel & Capacities
1.25 gal
4.7 L
Transmission
5 forward and reverse
Overview
 | 1987 - 1989
6 SeriesRiding lawn mower
6 Series
Riding lawn mower |
|---|
Production | |
|---|---|
Manufacturer | Snapper |
Riding lawn mower | |
Snapper 30106 Engine | |
|---|---|
10HP Briggs & Stratton gasoline | |
Fuel tank | 1.25 gal
4.7 L |
Engine details ...  | |
Snapper 30106 Transmission | |
|---|---|
5-speed friction disc | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering |
Dimensions & Tires | |
|---|---|
Front tire | 10.5x4.1-4 |
Rear tire | 16x6.5-8 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
Rear engine riding mowers published in 1989, by Snapper |
Engine
Engine Detail — Gasoline
Manufacturer | Briggs & Stratton |
Fuel Type | Gasoline |
Configuration | air-cooled vertical-shaft |
Power (gross) | 10 hp
7.5 kW |
Starter | electric |
Starter volts | 12 |
Transmission
Transmission — 5 forward and reverse friction disc
Type | friction disc |
Gears | 5 forward and reverse |
Dimensions
Snapper 30106 Tires | |
|---|---|
Lawn/turf front | 10.5x4.1-4 |
Lawn/turf rear | 16x6.5-8 |
Dimensions |
|---|
Attachments
30" Mower deck | |
|---|---|
Type | mid-mount Snapper |
1-blade with manual lift | |
Cutting width | 30 inches
76 cm |
Cut height | 1 to 4 inch
2 to 10 cm |
Cut positions | 6 |
Photos
Snapper 30106 tractor photo
Snapper Lawn Tractors Snapper 30106 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Snapper Lawn Tractors Snapper 30106.
Converted Equivalents:
Horsepower (HP)10 hp
Kilowatts (kW)7.5 kW
Metric Horsepower (PS / CV)10.1 PS
