Snapper LT145H38HBV
The Snapper LT145H38HBV is a tractor produced by Snapper Lawn Tractors. It is equipped with a 465 cc 28.4 ci engine. The listed engine power is Gasoline (gross): 14.5 hp / 10.8 kW. Transmission: Tuff Torq K-46. Operating weight: 407 lbs 184 kg.
Engine Power
Gasoline (gross): 14.5 hp / 10.8 kW
Fuel & Capacities
2 gal
7.6 L
Transmission
Tuff Torq K-46
Operating Weight
407 lbs
184 kg
Overview
 | 2002
LT H SeriesLawn tractor
LT H Series
Lawn tractor |
|---|
Production | |
|---|---|
Manufacturer | Snapper |
Lawn tractor | |
Snapper LT145H38HBV Engine | |
|---|---|
14.5HP Briggs & Stratton 465cc 1-cyl gasoline | |
Fuel tank | 2 gal
7.6 L |
Engine details ...  | |
Snapper LT145H38HBV Transmission | |
|---|---|
hydrostatic | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Disc brakes | |
Open operator station. |
Power Take-off (PTO) | |
|---|---|
Mid PTO | independent |
Clutch | manual |
Dimensions & Tires | |
|---|---|
Weight | 407 lbs
184 kg |
Front tire | 13x5.00-6 |
Rear tire | 18x7.00-8 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging amps | 3 |
Battery CCA | 220 |
Battery volts | 12 |
References | |
|---|---|
 | |
Residential Product Catalog published in 2002, by Snapper |
Engine
Engine Detail — 465 cc / 28.4 ci Gasoline
Manufacturer | Briggs & Stratton |
Fuel Type | Gasoline |
Configuration | 1-cylinder, air-cooled vertical-shaft |
Displacement | 465 cc
28.4 ci |
Bore/Stroke | 3.44x3.06 inches
87 x 78 mm |
Power (gross) | 14.5 hp
10.8 kW |
Air cleaner | dual element |
Starter | electric |
Starter volts | 12 |
Transmission
Transmission — Tuff Torq K-46
Transmission | Tuff Torq K-46 |
Type | belt-driven hydrostatic |
Gears | infinite forward and reverse |
 | |
Dimensions
Snapper LT145H38HBV Tires | |
|---|---|
Lawn/turf front | 13x5.00-6 |
Lawn/turf rear | 18x7.00-8 |
Dimensions | |
|---|---|
Weight | 407 lbs
184 kg |
Attachments
Attachment overview | |
|---|---|
38" mid-mount mower deck | |
Snowblower | |
Blade |
38" Mower deck | |
|---|---|
Type | mid-mount Snapper |
2-blade | |
Cutting width | 38 inches
96 cm |
Cut height | 1.25 to 3.75 inch
3 to 9 cm |
Cut positions | 6 |
Photos
Snapper LT145H38HBV tractor photo
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Snapper Lawn Tractors Snapper LT145H38HBV.
Estimated Continuous Field Runtime: 2.7 hrs
Approximately 2.7 hours of continuous field operation at ~75% rated power on a full tank (2 gal / 7.6 L).
Estimated 75% Load Fuel Burn~0.8 gal/hr (2.9 L/hr)
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Snapper Lawn Tractors Snapper LT145H38HBV Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Snapper Lawn Tractors Snapper LT145H38HBV.
Converted Equivalents:
Horsepower (HP)14.5 hp
Kilowatts (kW)10.8 kW
Metric Horsepower (PS / CV)14.7 PS
