Stihl 144
The Stihl 144 is a tractor produced by Stihl. It is equipped with a 46.56 ci 0.8 L engine. The listed engine power is Diesel (listed): 14 hp / 10.4 kW. Transmission: Hurth. Operating weight: 1,698 lbs 770 kg.
Engine Power
Diesel (listed): 14 hp / 10.4 kW
Fuel & Capacities
Diesel
Transmission
Hurth
Operating Weight
1,698 lbs
770 kg
Overview
 | 1955 - 1958 |
|---|
Production | |
|---|---|
Manufacturer | Stihl |
Stihl 144 Engine | |
|---|---|
Stihl 0.8L 1-cyl diesel | |
Engine details ...  |
Stihl 144 Transmission | |
|---|---|
4-speed unsynchronized gear | |
Transmission details ...  |
Stihl 144 Power | |
|---|---|
Engine | 14 hp
10.4 kW |
Mechanical | |
|---|---|
Two-wheel drive | |
Band brakes | |
Open operator station. |
Dimensions & Tires | |
|---|---|
Weight | 1,698 lbs
770 kg |
Front tire | 4.50-16 |
Rear tire | 7.00-30 |
Full dimensions and tires ...  | |
Engine
Engine Detail — 46.56 ci / 0.8 L Diesel
Manufacturer | Stihl 131 |
Fuel Type | Diesel |
Configuration | 1-cylinder, air-cooled |
Displacement | 46.56 ci
0.8 L |
Power | 14 hp
10.4 kW |
Rated RPM | 2000 |
Starter volts | 12 |
Transmission
Transmission — Hurth
Transmission | Hurth |
Type | unsynchronized gear |
Gears | 4 forward and 1 reverse |
Dimensions
Stihl 144 Tires | |
|---|---|
Standard tires (ag) | Front: 4.50-16. Rear: 7.00-30 |
Dimensions | |
|---|---|
Weight | 1,698 lbs
770 kg |
Photos
Stihl 144 tractor.
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Stihl 144.
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Stihl 144 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Stihl 144.
Converted Equivalents:
Horsepower (HP)14 hp
Kilowatts (kW)10.4 kW
Metric Horsepower (PS / CV)14.2 PS
