Toro 4 HP 57000
The Toro 4 HP 57000 is a tractor produced by Toro Lawn Tractors. It is equipped with a 170 cc 10.4 ci engine. The listed engine power is Gasoline (gross): 4 hp / 3.0 kW. Transmission: 2 forward and 1 reverse.
Engine Power
Gasoline (gross): 4 hp / 3.0 kW
Fuel & Capacities
Gasoline
Transmission
2 forward and 1 reverse
Overview
 | 1967
Lawn tractor |
|---|
Production | |
|---|---|
Manufacturer | Toro |
Lawn tractor | |
Original price was $280 in 1967 | |
Toro 4 HP Engine | |
|---|---|
4HP Briggs & Stratton 170cc 1-cyl gasoline | |
Engine details ...  |
Toro 4 HP Transmission | |
|---|---|
2-speed gear | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Open operator station. |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Dimensions & Tires | |
|---|---|
Full dimensions and tires ...  |
References | |
|---|---|
 | |
Toro 1967 |
Engine
Engine Detail — 170 cc / 10.4 ci Gasoline
Manufacturer | Briggs & Stratton 100902 |
Fuel Type | Gasoline |
Configuration | 1-cylinder, air-cooled vertical-shaft |
Displacement | 170 cc
10.4 ci |
Bore/Stroke | 2.50x2.18 inches
64 x 55 mm |
Power (gross) | 4 hp
3.0 kW |
Starter type | recoil |
Transmission
Transmission — 2 forward and 1 reverse belt-driven gear
Type | belt-driven gear |
Gears | 2 forward and 1 reverse |
Dimensions
Toro 4 HP Tires |
|---|
Dimensions |
|---|
Attachments
25" Mower deck | |
|---|---|
Type | mid-mount Toro |
1-blade | |
Cutting width | 25 inches
63 cm |
Photos
Toro 4 HP 57000 tractor photo
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Toro Lawn Tractors Toro 4 HP 57000.
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Toro Lawn Tractors Toro 4 HP 57000 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Toro Lawn Tractors Toro 4 HP 57000.
Converted Equivalents:
Horsepower (HP)4 hp
Kilowatts (kW)3 kW
Metric Horsepower (PS / CV)4.1 PS
