Versatile 250
The Versatile 250 is a tractor produced by Versatile. It is equipped with a 506 ci 8.3 L engine. The rated power output is 250 hp 186.4 kW. Transmission: power shift. Operating weight: 17700 to 20050 pounds.
Engine Power
250 hp
186.4 kW
Fuel & Capacities
110 gal
416.4 L
Transmission
power shift
Operating Weight
17700 to 20050 pounds
Versatile 250 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 2009 - 2014
Model year 2009-20112012-2014
Row-Crop tractor |
|---|---|
2009 - 2014 | |
Model year 2009-20112012-2014 | |
Row-Crop tractor | |
Production | |
|---|---|
Manufacturer | Versatile |
Row-Crop tractor | |
Built in Winnipeg, Manitoba, Canada | |
Versatile 250 Engine | |
|---|---|
Cummins 8.3L 6-cyl diesel | |
Engine details ...  |
Versatile 250 Transmission | |
|---|---|
18-speed | |
Transmission details ...  |
Versatile 250 Power | |
|---|---|
Engine | 250 hp
186.4 kW |
PTO (claimed) | 200 hp
149.1 kW |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Power steering | |
Cab standard |
Capacity | |
|---|---|
Fuel | 110 gal
416.4 L |
Hydraulic system | 31 gal
117.3 L |
Hydraulics | |
|---|---|
Type | closed center load sensing |
Capacity | 31 gal
117.3 L |
Pressure | 2900 psi
200.0 bar |
Valves | 3 to 4 |
Total flow | 30 gpm
113.6 lpm |
55 gpmOptOptional
208.2 lpm | |
Tractor hitch | |
|---|---|
Rear Type | III |
Rear lift | 15,000 lbs
6804 kg |
Dimensions & Tires | |
|---|---|
Wheelbase | 121 inches (standard)
307 cm |
125 inches (Ultra Steer)
317 cm | |
Weight | 17700 to 20050 pounds |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Charging system | alternator |
Charging amps | 130 |
160 OptOptional | |
Batteries | 2 |
Battery CCA | 950 |
Battery volts | 12 |
Engine
Engine Detail — 506 ci / 8.3 L Diesel
Manufacturer | Cummins QSC |
Configuration | turbocharged aftercooled diesel, 6-cylinder, liquid-cooled |
Displacement | 506 ci
8.3 L |
Bore/Stroke | 4.488x5.315 inches
114 x 135 mm |
Power | 250 hp
186.4 kW |
Rated RPM | 2200 |
Torque | 830 lb-ft
1125.5 Nm |
Torque RPM | 1400 |
Oil capacity | 20 qts
18.9 L |
Coolant capacity | 29 qts
27.4 L |
Transmission
Transmission — power shift
Transmission | power shift |
Gears | 18 forward and 9 reverse |
 | |
Dimensions
Versatile 250 Tires |
|---|
Dimensions | |
|---|---|
Wheelbase | 121 inches (standard)
307 cm |
125 inches (Ultra Steer)
317 cm | |
Length | 200 inches (standard)
508 cm |
205 inches (Ultra Steer)
520 cm | |
Height (cab) | 125 inches
317 cm |
Height (exhaust) | 126 inches
320 cm |
Ground clearance | 18.6 inches
47 cm |
Versatile 250 Weight | |
|---|---|
Shipping | 17,700 lbs (2WD)
8028 kg |
19,150 lbs (4WD)
8686 kg | |
20,050 lbs (UltraSteer)
9094 kg | |
Photos
