Versatile 250
The Versatile 250 is a tractor produced by Versatile. It is equipped with a 506 ci 8.3 L engine. The listed engine power is Diesel (listed): 250 hp / 186.4 kW. Transmission: power shift. Operating weight: 17700 to 20050 pounds.
Engine Power
Diesel (listed): 250 hp / 186.4 kW
Fuel & Capacities
110 gal
416.4 L
Transmission
power shift
Operating Weight
17700 to 20050 pounds
Overview
 | 2009 - 2014
Model year 2009-20112012-2014
Row-Crop tractor |
|---|
Production | |
|---|---|
Manufacturer | Versatile |
Row-Crop tractor | |
Built in Winnipeg, Manitoba, Canada | |
Versatile 250 Engine | |
|---|---|
Cummins 8.3L 6-cyl diesel | |
Engine details ...  |
Versatile 250 Transmission | |
|---|---|
18-speed | |
Transmission details ...  |
Versatile 250 Power | |
|---|---|
Engine | 250 hp
186.4 kW |
PTO (claimed) | 200 hp
149.1 kW |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Power steering | |
Cab standard |
Capacity | |
|---|---|
Fuel | 110 gal
416.4 L |
Hydraulic system | 31 gal
117.3 L |
Hydraulics | |
|---|---|
Type | closed center load sensing |
Capacity | 31 gal
117.3 L |
Pressure | 2900 psi
200.0 bar |
Valves | 3 to 4 |
Total flow | 30 gpm
113.6 lpm |
55 gpmOptOptional
208.2 lpm | |
Tractor hitch | |
|---|---|
Rear Type | III |
Rear lift | 15,000 lbs
6804 kg |
Dimensions & Tires | |
|---|---|
Wheelbase | 121 inches (standard)
307 cm |
125 inches (Ultra Steer)
317 cm | |
Weight | 17700 to 20050 pounds |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Charging system | alternator |
Charging amps | 130 |
160 OptOptional | |
Batteries | 2 |
Battery CCA | 950 |
Battery volts | 12 |
Engine
Engine Detail — 506 ci / 8.3 L Diesel
Manufacturer | Cummins QSC |
Configuration | turbocharged aftercooled diesel, 6-cylinder, liquid-cooled |
Displacement | 506 ci
8.3 L |
Bore/Stroke | 4.488x5.315 inches
114 x 135 mm |
Power | 250 hp
186.4 kW |
Rated RPM | 2200 |
Torque | 830 lb-ft
1125.5 Nm |
Torque RPM | 1400 |
Oil capacity | 20 qts
18.9 L |
Coolant capacity | 29 qts
27.4 L |
Transmission
Transmission — power shift
Transmission | power shift |
Gears | 18 forward and 9 reverse |
 | |
Dimensions
Versatile 250 Tires |
|---|
Dimensions | |
|---|---|
Wheelbase | 121 inches (standard)
307 cm |
125 inches (Ultra Steer)
317 cm | |
Length | 200 inches (standard)
508 cm |
205 inches (Ultra Steer)
520 cm | |
Height (cab) | 125 inches
317 cm |
Height (exhaust) | 126 inches
320 cm |
Ground clearance | 18.6 inches
47 cm |
Versatile 250 Weight | |
|---|---|
Shipping | 17,700 lbs (2WD)
8028 kg |
19,150 lbs (4WD)
8686 kg | |
20,050 lbs (UltraSteer)
9094 kg | |
Photos
Versatile 250
Recommended Implements & Sizing Guide
Engineering recommendations for Versatile 250 based on its 250 HP power envelope and ASAE agricultural standards.
| Implement & Operation | Recommended Size | Workload Rating | Engineering Notes |
|---|---|---|---|
Moldboard PlowPrimary Tillage | 8+ Bottom On-Land Hitch8+ 铧重型机外牵引犁 | Commercial / Field Scale | High horsepower articulated/4WD field plowing. |
Rotary Cutter / MowerMowing & Clearing | 15 to 20 ft Batwing4.6 - 6.1 m 宽幅折叠翼 | Commercial / Field Scale | Large commercial field and roadside mowing operations. |
Rotary TillerSeedbed Prep | 90 to 120 in Heavy Duty230 - 300 cm 重型旋耕机 | Commercial / Field Scale | Deep intensive seedbed preparation for commercial row crops. |
Disc HarrowSecondary Tillage | 24 to 36 ft Heavy Duty Field Disc7.3 - 11.0 m 超宽重型整地耙 | Commercial / Field Scale | Broad-acre grain tillage for high-drawbar tractors. |
Hay BalerHay & Forage | Large Square Baler (3x4 or 4x4)大方捆商用打捆机 (1.2x1.2 m) | Commercial / Field Scale | High-capacity commercial forage harvesting (1000 RPM PTO). |
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Versatile 250.
Estimated Continuous Field Runtime: 8.5 hrs
Approximately 8.5 hours of continuous field operation at ~75% rated power on a full tank (110 gal / 416.4 L).
Estimated 75% Load Fuel Burn~13 gal/hr (49.2 L/hr)
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Versatile 250 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Versatile 250.
Converted Equivalents:
Horsepower (HP)250 hp
Kilowatts (kW)186.4 kW
Metric Horsepower (PS / CV)253.5 PS
Direct Competitor Comparison
Compare Versatile 250 against same-era industry alternatives in the same horsepower class.
Current Model
Versatile
Versatile 250
Engine Power:Diesel (listed): 250 hp / 186.4 kW
★ Baseline Reference
International HarvesterMarket Competitor
International Harvester 4366
Engine Power:225
Production Years:1973 - 1976
