wheel horse lawn tractors 416 8
 | 1985 - 1992
400 SeriesGarden tractor | 1985 - 1992 | 400 Series | Garden tractor |
|---|---|---|---|---|
1985 - 1992 | ||||
400 Series | ||||
Garden tractor | ||||
1985 - 1992 | |
|---|---|
400 Series | |
Garden tractor |
Production | |
|---|---|
Manufacturer | Wheel Horse (a part of Toro) |
Garden tractor | |
Built in South Bend, Indiana, USA | |
Original price was $2950 in 1990 | |
Variants | |
|---|---|
416-8 | gear |
416-H | hydro |
Wheel Horse 416-8 Engines | |
|---|---|
16HP Kohler 588cc 1-cyl gasoline | |
16HP Onan 709cc 2-cyl gasoline | |
Fuel tank | 2.25 gal
8.5 L |
Engine details ...  | |
Wheel Horse 416-8 Transmission | |
|---|---|
6-speed gear | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Open operator station. |
Photos | |
|---|---|
 | |
Wheel Horse 416-8 photos...  |
Power Take-off (PTO) | |
|---|---|
Front PTO | independent |
Clutch | mechanical |
Dimensions & Tires | |
|---|---|
Wheelbase | 45.5 inches
115 cm |
Weight | 553 to 658 pounds |
Front tire | 15x6.00-6 |
Rear tire | 23x9.50-12 |
Full dimensions and tires ...  | |
Wheel Horse 416-8 attachments | |
|---|---|
36" mid-mount mower deck | |
42" mid-mount mower deck | |
48" mid-mount mower deck | |
snowblower | |
blade | |
front-end loader | |
Attachment details ...  |
416-8 Serial Numbers | |
|---|---|
Location: | Model codes shown. |
1985 | 31-16K801 |
1986 | 31-16K802 |
1987 | 31-16K803 |
1988 | 31-16K804 |
1989 | 31-16O801 |
1990 | 31-16O802 |
1991 | 31-16O803 |
1992 | 31-16O804 |
FAQ: How to read a serial number table. | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
Loader Model 45-08210 published in 1987, by Toro | |
Lawn and Garden Tractors published in 1996, by Toro | |
Nothing works like a horse. Wheel Horse... of course! published in 1986 | |
Wheel Horse Lawn & Garden Equipment published in 1986 | |
Wheel Horse Lawn & Garden Equipment published in 1988 | |
Wheel Horse Lawn & Garden Equipment published in 1989 | |
Wheel Horse Lawn & Garden Equipment published in 1990 | |
1991 Toro Wheel Horse Garden Tractors | |
Garden Tractors Zero-Radius Tractors 1992 Catalog published by Wheel Horse | |
Operators Manual 200 Series, 300 Series, 400 Series (810339R1) published in 1986 |
