white 6510

White 6510 tractor photo
1998 - 2001 6010 SeriesUtility tractor
1998 - 2001
6010 Series
Utility tractor
1998 - 2001
6010 Series
Utility tractor
1998 - 2001
6010 Series
Utility tractor
Production
Manufacturer
White (a part of AGCO)
Utility tractor
Original price was $36,000 in 1999
Variants
8765
similar AGCO Allis model
White 6510 Engine
Cummins 3.9L 4-cyl diesel
ROPS Fuel tank
33.5 gal 126.8 L
Cab Fuel tank
34 gal 128.7 L
Engine details ...
White 6510 Transmissions
12-speed partially synchronized
12-speed synchronized shuttle
24-speed power shuttle
Transmission details ...
White 6510 Power
PTO (claimed)
85 hp 63.4 kW
Mechanical
Two- or four-wheel drive
Final drives
outboard planetary
Differential lock
electro-hydraulic front and rear
Power steering
Hydraulic wet disc brakes
Two-post folding ROPS. Cab optional with air-conditioning. FieldStar ready
Hydraulics
Type
open center
Pressure
3045 psi 210.0 bar
Valves
2
Pump flow
7.9 gpm (hitch) 29.9 lpm

10 gpm (remote) 37.9 lpm
Total flow
25.8 gpm 97.7 lpm
Steering flow
7.9 gpm 29.9 lpm
Tractor hitch
Rear Type
II
Rear lift (at 24"/610mm)
4100 lbs 1859 kg

6200 lbsOptOptional 2812 kg
Power Take-off (PTO)
Rear PTO
independent
Clutch
wet disc
Rear PTO Type
540/1000
Dimensions & Tires
Wheelbase
99 inches 251 cm
Weight
7870 to 8650 pounds
Front tire
9.5L-15
Rear tire
13.6R38
Full dimensions and tires ...
White 6510 attachments
front-end loader
Attachment details ...
6510 Serial Numbers
1998
G01001
1999
H01001
FAQ: How to read a serial number table.
References
6510 references literature
White Loaders published in 1999, by AGCO
6410 - 6510 - 6710 - 6810 published by AGCO
6010 Series published in 1998, by AGCO
