Zetor M40
The Zetor M40 is a tractor produced by Zetor. The listed engine power is Diesel (listed): 38 hp / 28.3 kW. Transmission: infinite forward and reverse (3-range).
Engine Power
Diesel (listed): 38 hp / 28.3 kW
Fuel & Capacities
Diesel
Transmission
infinite forward and reverse (3-range)
Overview
![]() | 2020 -
M Compact SeriesCompact Utility tractor |
|---|---|
2020 - | |
M Compact Series | |
Compact Utility tractor | |
Production | |
|---|---|
Manufacturer | Zetor |
Compact Utility tractor | |
Zetor M40 Engine | |
|---|---|
Yanmar 3-cyl diesel | |
Engine details ... |
Zetor M40 Power | |
|---|---|
Engine | 38 hp
28.3 kW |
Shuttle PTO (claimed) | 31.8 hp
23.7 kW |
Hydro PTO (claimed) | 29.9 hp
22.3 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Power steering | |
Two-post folding ROPS. Cab optional. |
Hydraulics | |
|---|---|
Pump flow | 11.2 gpm
42.4 lpm |
Tractor hitch | |
|---|---|
Rear lift | 2646 lbs
1200 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Clutch | electro-hydraulic wet disc |
Rear PTO Type | 540 (1.375) |
Dimensions & Tires | |
|---|---|
Full dimensions and tires ... |
References | |
|---|---|
![]() | |
M Series Product Guide published in 2020, by Zetor |
Engine
Engine Detail — Diesel
Manufacturer | Yanmar |
Fuel Type | Diesel |
Configuration | 3-cylinder, liquid-cooled |
Power | 38 hp
28.3 kW |
Starter type | electric |
Transmission
Transmission options | |
|---|---|
12-speed shuttle | |
hydrostatic |
Transmission — 12 forward and reverse shuttle
Type | shuttle |
Gears | 12 forward and reverse |
Transmission — infinite forward and reverse (3-range) hydrostatic
Type | hydrostatic |
Gears | infinite forward and reverse (3-range) |
Dimensions
Zetor M40 Tires |
|---|
Dimensions |
|---|
Recommended Implements & Sizing Guide
Engineering recommendations for Zetor M40 based on its 38 HP power envelope and ASAE agricultural standards.
| Implement & Operation | Recommended Size | Workload Rating | Engineering Notes |
|---|---|---|---|
Moldboard PlowPrimary Tillage | 2 to 3 Bottom (14-16")2 - 3 铧 (35-40 cm) | Medium Duty | Standard utility farm tillage. |
Rotary Cutter / MowerMowing & Clearing | 5 ft (60 in)1.5 m | Medium Duty | Pasture maintenance and weeds up to 1.5" diameter. |
Rotary TillerSeedbed Prep | 54 to 60 in135 - 150 cm | Medium Duty | Thorough seedbed preparation in orchards and vegetable plots. |
Disc HarrowSecondary Tillage | 5 to 6 ft (16-18" discs)1.5 - 1.8 m (40-45 cm 耙片) | Light Duty | Small acreage soil break-up and secondary aeration. |
Hay BalerHay & Forage | Small Square Baler (14x18")小方捆打捆机 (36x46 cm) | Medium Duty | Classic 2-string baler for horse and small livestock hay. |
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Zetor M40.
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Zetor M40 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Zetor M40.
Converted Equivalents:
Horsepower (HP)38 hp
Kilowatts (kW)28.3 kW
Metric Horsepower (PS / CV)38.5 PS
Direct Competitor Comparison
Compare Zetor M40 against same-era industry alternatives in the same horsepower class.
Current Model
Zetor
Zetor M40
Engine Power:Diesel (listed): 38 hp / 28.3 kW
★ Baseline Reference
International HarvesterMarket Competitor
International Harvester TD-6
Engine Power:34.4
Production Years:1940 - 1969
