Zetor M70

The Zetor M70 is a tractor produced by Zetor. The listed engine power is Diesel (net): 67 hp / 50.0 kW; Diesel (gross): 72.8 hp / 54.3 kW. Transmission: 24 forward and reverse.

Engine Power
Diesel (net): 67 hp / 50.0 kW; Diesel (gross): 72.8 hp / 54.3 kW
Fuel & Capacities
Diesel
Transmission
24 forward and reverse

Overview

No photo available
2020 - M Compact SeriesCompact Utility tractor
2020 -
M Compact Series
Compact Utility tractor
Production
Manufacturer
Zetor
Compact Utility tractor
Zetor M70 Engine
Deutz 4-cyl diesel
Engine details ...
Zetor M70 Transmission
24-speed power shuttle
Transmission details ...
Zetor M70 Power
Engine (gross)
72.8 hp 54.3 kW
Engine (net)
67 hp 50.0 kW
PTO (claimed)
62 hp 46.2 kW
Mechanical
Four-wheel drive
Power steering
Cab standard.
Hydraulics
Pump flow
16.1 gpm 60.9 lpm
Tractor hitch
Rear Type
II/I
Control
position and draft control
Rear lift
4270 lbs 1936 kg
Power Take-off (PTO)
Rear PTO
independent
Clutch
electro-hydraulic wet disc
Rear PTO Type
540/540E/1000 (1.375)
Dimensions & Tires
Full dimensions and tires ...
References
M70 references literature
M Series Product Guide published in 2020, by Zetor

Engine

Engine Detail — Diesel

Manufacturer
Deutz
Fuel Type
Diesel
Configuration
4-cylinder, liquid-cooled
Power (net)
67 hp 50.0 kW
Power (gross)
72.8 hp 54.3 kW
Starter type
electric

Transmission

Transmission — 24 forward and reverse power shuttle

Type
power shuttle
Gears
24 forward and reverse

Dimensions

Zetor M70 Tires
Dimensions

Zetor M70 Specification Unit Converter

Convert power, fluid capacities, and operating weights between metric and imperial standards for Zetor M70.

Converted Equivalents:

Horsepower (HP)0 hp
Kilowatts (kW)0 kW
Metric Horsepower (PS / CV)0 PS
