bolens lawn tractors 628
 | 1980 - 1982
Riding lawn mower | 1980 - 1982 | Riding lawn mower |
|---|---|---|---|
1980 - 1982 | |||
Riding lawn mower | |||
1980 - 1982 | |
|---|---|
Riding lawn mower |
Production | |
|---|---|
Manufacturer | Bolens |
Riding lawn mower | |
Bolens 628 Engine | |
|---|---|
6HP Briggs & Stratton 1-cyl gasoline | |
Fuel tank | 0.5 gal
1.9 L |
Engine details ...  | |
Bolens 628 Transmission | |
|---|---|
5-speed gear | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Disc brakes | |
Open operator station. |
Power Take-off (PTO) | |
|---|---|
Mid PTO | independent |
Clutch | mechanical idler pulley |
Dimensions & Tires | |
|---|---|
Weight | 365 lbs
165 kg |
Front tire | 3.5x10 |
Rear tire | 4.8x16.8 |
Full dimensions and tires ...  | |
Bolens 628 attachments | |
|---|---|
28" mid-mount mower deck | |
Attachment details ...  |
References | |
|---|---|
 | |
Lawn Machines published in 1981, by Bolens | |
Equipment Seminar published in 1982 |
